Schweitzer Engineering Laboratories SEL-751 - Page 427

Date Code 20170927 Instruction Manual SEL-751 Relay
SET.55
of 78
Date _______________ SEL-751 Settings Sheets
PORT 4 SET PORT p (p = F, 1, 2, 3, or 4) Command
MIRRORED BITS Protocol
(Hidden if PROTO := SEL, EVMSG, or MOD)
IEC 60870-5-103 Protocol
(Hidden unless serial port with PROTO := 103)
PORT 4
(EIA-232/485 Port or DeviceNet Port in Slot C)
Interface Select
(Hidden if PROTO := DNET)
MB Transmit Identifier
(1-4) TXID :=
MB Receive Identifier
(1-4) RXID :=
MB RX Bad Pickup Time
(0–10000 s) RBADPU :=
MB Channel Bad Pickup
(1–10000 ppm) CBADPU :=
MB Receive Default State
(8 characters) RXDFLT :=
RMB1 Pickup Debounce
Messages (1–8) RMB1PU :=
RMB1 Dropout Debounce
Messages (1–8) RMB1DO :=
RMB2 Pickup Debounce
Messages (1–8) RMB2PU :=
RMB2 Dropout Debounce
Messages (1–8) RMB2DO :=
RMB3 Pickup Debounce
Messages (1–8) RMB3PU :=
RMB3 Dropout Debounce
Messages (1–8) RMB3DO :=
RMB4 Pickup Debounce
Messages (1–8) RMB4PU :=
RMB4 Dropout Debounce
Messages (1–8) RMB4DO :=
RMB5 Pickup Debounce
Messages (1–8) RMB5PU :=
RMB5 Dropout Debounce
Messages (1–8) RMB5DO :=
RMB6 Pickup Debounce
Messages (1–8) RMB6PU :=
RMB6 Dropout Debounce
Messages (1–8) RMB6DO :=
RMB7 Pickup Debounce
Messages (1–8) RMB7PU :=
RMB7 Dropout Debounce
Messages (1–8) RMB7DO :=
RMB8 Pickup Debounce
Messages (1–8) RMB8PU :=
RMB8 Dropout Debounce
Messages (1–8) RMB8DO :=
103 DEVICE ADDRESS (0–254) 103ADDR :=
CYCLIC DATA REPORTING PERIOD (1–3600 s) 103CYC :=
ACCUMULATOR REPORTING PERIOD (OFF, 1–3600 s) 103ACYC :=
ACCUMULATOR REPORTING TRIGGER (1 Relay Word Bit) 103ATRI :=
ENABLE TIME SYNCHRONIZATION (Y, N) 103TIME :=
ENABLE PORT (Y, N) EPORT :=
PROTOCOL (SEL, DNP, MOD, DNET, EVMSG, PMU, MBA, MBB, MB8A,
MB8B, MBTA, MBTB, 103) PROTO :=
MAXIMUM ACCESS LEVEL (1, 2, C) MAXACC :=
COMM INTERFACE (232, 485) COMMINF :=
