Date Code 20170927 Instruction Manual SEL-751 Relay
SET.57
of 78
Date _______________ SEL-751 Settings Sheets
PORT 4 SET PORT p (p = F, 1, 2, 3, or 4) Command
Modem Protocol
(For DNP3 session and EIA-232 port only)
MIRRORED BITS Protocol
(Hidden if PROTO := SEL, EVMSG, or MOD)
Seconds to Data Link Time-Out (0–5) (Hidden if DRETRY1 := 0) DTIMEO1 :=
Event Message Confirm Time-Out (1–50 s) ETIMEO1 :=
Enable Unsolicited Reporting (Y, N) (Hidden if ECLASSA1 := 0, ECLASSB1 := 0,
ECLASSC1 := 0, and ECLASSV1 := 0) UNSOL1 :=
Enable Unsolicited Reporting at Power-Up (Y, N) (HiddenifUNSOL1:=N) PUNSOL1 :=
Number of Events to Transmit On (1–200) (Hidden if UNSOL1 := N) NUMEVE1 :=
Oldest Event to Tx On (0.0–99999.0 s) (HiddenifUNSOL1:=N) AGEEVE1 :=
Unsolicited Message Max Retry Attempts (2–10) (HiddenifUNSOL1:=N) URETRY1 :=
Unsolicited Message Offline Time-Out (1–5000 s) (HiddenifUNSOL1:=N) UTIMEO1 :=
Minimum Seconds from DCD to TX (0.00–1.00) MINDLY :=
Maximum Seconds from DCD to TX (0.00–1.00) MAXDLY :=
Settle Time from RTS On to TX (OFF, 0.00–30.00 s) PREDLY :=
Settle Time from TX to RTS OFF (0.00–30.00 s) PSTDLY :=
Modem Connected to Port (Y, N) MODEM :=
Modem Startup String (30 characters) MSTR :=
Phone Number for Dial-Out (30 characters) PH_NUM1 :=
Phone Number for Dial-Out (30 characters) PH_NUM2 :=
Retry Attempts for Phone 1 Dial-Out (1–20) RETRY1 :=
Retry Attempts for Phone 2 Dial-Out (1–20) RETRY2 :=
Time to Attempt Dial (5–300 s) MDTIME :=
Time Between Dial-Out Attempts (5–3600 s) MDRET :=
MB Transmit Identifier
(1–4) TXID :=
MB Receive Identifier
(1–4) RXID :=
MB RX Bad Pickup Time
(0–10000 s) RBADPU :=
MB Channel Bad Pickup
(1–10000 ppm) CBADPU :=
MB Receive Default State
(8 characters) RXDFLT :=
RMB1 Pickup Debounce
Messages (1–8) RMB1PU :=
RMB1 Dropout Debounce
Messages (1–8) RMB1DO :=
RMB2 Pickup Debounce
Messages (1–8) RMB2PU :=
RMB2 Dropout Debounce
Messages (1–8) RMB2DO :=
RMB3 Pickup Debounce
Messages (1–8) RMB3PU :=
RMB3 Dropout Debounce
Messages (1–8) RMB3DO :=
RMB4 Pickup Debounce
Messages (1–8) RMB4PU :=
RMB4 Dropout Debounce
Messages (1–8) RMB4DO :=
RMB5 Pickup Debounce
Messages (1–8) RMB5PU :=
RMB5 Dropout Debounce
Messages (1–8) RMB5DO :=
RMB6 Pickup Debounce
Messages (1–8) RMB6PU :=
RMB6 Dropout Debounce
Messages (1–8) RMB6DO :=
RMB7 Pickup Debounce
Messages (1–8) RMB7PU :=
RMB7 Dropout Debounce
Messages (1–8) RMB7DO :=
