SEL-751 Settings Sheets Date________________
Front-Panel Settings (SET F Command) General
SEL-751 Relay Instruction Manual Date Code 20170927
IEC 60870-5-103 Protocol
(Hidden unless serial port with PROTO := 103)
Front-Panel Settings (SET F Command)
General
Target LED
(R = Red, G = Green, A = Amber)
RMB8 Pickup Debounce
Messages (1–8) RMB8PU :=
RMB8 Dropout Debounce
Messages (1–8) RMB8DO :=
103 DEVICE ADDRESS (0–254) 103ADDR :=
CYCLIC DATA REPORTING PERIOD (1–3600 s) 103CYC :=
ACCUMULATOR REPORTING PERIOD (OFF, 1–3600 s) 103ACYC :=
ACCUMULATOR REPORTING TRIGGER (1 Relay Word Bit) 103ATRI :=
ENABLE TIME SYNCHRONIZATION (Y, N) 103TIME :=
DISPLY PTS ENABL (N, 1–32)
(Hidden and forced to N if the front-panel MOT option is A) EDP :=
LOCAL BITS ENABL (N, 1–32) ELB :=
LCD TIMEOUT (OFF, 1–30 min)
(Hidden and forced to OFF if the front-panel MOT option is A) FP_TO :=
LCD CONTRAST (1–8)
(Hidden if the front-panel MOT option is A) FP_CONT :=
FP AUTOMESSAGES (OVERRIDE, ROTATING)
(Hidden if the front-panel MOT option is A) FP_AUTO :=
CLOSE RESET LEDS (Y, N) RSTLED :=
ENA_LED COLOR (R = Red, G = Green, A = Amber)
(Hidden if the front-panel MOT option is A) LEDENAC :=
TRIP_LED COLOR (R = Red, G = Green, A = Amber) LEDTRPC :=
MAXIMUM ACCESS LEVEL (1, 2)
(Hidden if the front-panel MOT option is A) MAXACC :=
TRIP LATCH T_LED (Y, N) T01LEDL :=
TARGET T_LED ASSERTED COLOR (R, G, A) T01LEDC :=
LED1 EQUATION (SELOGIC) T01_LED :=
TRIP LATCH T_LED (Y, N) T02LEDL :=
TARGET T_LED ASSERTED COLOR (R, G, A) T02LEDC :=
LED2 EQUATION (SELOGIC) T02_LED :=
TRIP LATCH T_LED (Y, N) T03LEDL :=
TARGET T_LED ASSERTED COLOR (R, G, A) T03LEDC :=
LED3 EQUATION (SELOGIC) T03_LED :=
TRIP LATCH T_LED (Y, N) T04LEDL :=
