Date Code 20170927 Instruction Manual SEL-751 Relay
SET.63
of 78
Date _______________ SEL-751 Settings Sheets
Touchscreen Configuration Touchscreen Settings
Touchscreen Settings
(Shown if the front-panel MOT option is A)
(Note: The Touchscreen settings category is only available in QuickSet, with the exception of the settings FPTO, FPDUR,
and FPBAB, which are also available to set via the touchscreen display.)
Touchscreen Configuration
Rotating Display
(Refer to Table 8.17 for the setting range)
Pushbuttons
(OFF, refer to Table 8.17 for the setting range)
DISPLAY HOME SCREEN (Refer to Table 8.1 7 for setting range) FPHOME :=
DISPLAY TIME-OUT (1–30 min) FPTO :=
ROTATING DISPLAY TRANSITION TIME (3–15 sec) FPDUR :=
BACKLIGHT ACTIVE BRIGHTNESS (1–10) FPBAB :=
ROTATING DISPLAY 01 FPRD01 :=
ROTATING DISPLAY 02 FPRD02 :=
ROTATING DISPLAY 03 FPRD03 :=
ROTATING DISPLAY 04 FPRD04 :=
ROTATING DISPLAY 05 FPRD05 :=
ROTATING DISPLAY 06 FPRD06 :=
ROTATING DISPLAY 07 FPRD07 :=
ROTATING DISPLAY 08 FPRD08 :=
ROTATING DISPLAY 09 FPRD09 :=
ROTATING DISPLAY 10 FPRD10 :=
ROTATING DISPLAY 11 FPRD11 :=
ROTATING DISPLAY 12 FPRD12 :=
ROTATING DISPLAY 13 FPRD13 :=
ROTATING DISPLAY 14 FPRD14 :=
ROTATING DISPLAY 15 FPRD15 :=
ROTATING DISPLAY 16 FPRD16 :=
PUSHBUTTON 01 HMI SCREEN FPPB01 :=
PUSHBUTTON 02 HMI SCREEN FPPB02 :=
PUSHBUTTON 03 HMI SCREEN FPPB03 :=
PUSHBUTTON 04 HMI SCREEN FPPB04 :=
PUSHBUTTON 05 HMI SCREEN FPPB05 :=
PUSHBUTTON 06 HMI SCREEN FPPB06 :=
PUSHBUTTON 07 HMI SCREEN FPPB07 :=
PUSHBUTTON 08 HMI SCREEN FPPB08 :=
