Front-Panel Operations
Touchscreen Display Front Panel
TARGET RESET Pushbutton
Refer to TARGET RESET Pushbutton on page 8.14 for the operation of the
TARGET RESET pushbutton, the lamp test, and other target reset options.
Front-Panel Operator Control Pushbuttons
The SEL-751 touchscreen display features eight operator-controlled
pushbuttons, each with two programmable tricolor pushbutton LEDs, for local
control, as shown in Tabl e 8.4. Refer to Front-Panel Operator Control
Pushbuttons on page 8.15 for details on operator control pushbuttons and
LEDs and their programming.
You can use the front-panel operator control pushbuttons to jump to a specific
screen while using them for LOCK/OPEN/CLOSE operations, etc. You can
program the selectable operator pushbutton screen settings under the
Touchscreen settings category in QuickSet and map the button to a specific
screen. For example, PB04, which is used to trip a breaker by default, can be
programmed to jump to a bay screen by mapping the pushbutton touchscreen
setting FPPB04 to Bay Screen 1. When you press PB04, the display jumps to
Bay Screen 1, where you can see a visual confirmation of the TRIP action.
Table 8.17 Screens Available for the Rotating Display, HOME Pushbutton
a
, and Programmable Pushbuttons
(Sheet 1 of 8)
Home Screen
Folders and
Applications
Folder and
Application
Names
Display Name Quantities Comments
Bay Screens
Bay Screen 1 Displays Bay Screen 1
Bay Screen 2 Displays Bay Screen 2
Bay Screen 3 Displays Bay Screen 3
Bay Screen 4 Displays Bay Screen 4
Bay Screen 5 Displays Bay Screen 5
Meter
Phasors
Phasor Screen 1 IA_MAG, IA_ANG, IB_MAG,
IB_ANG, IC_MAG, IC_ANG
Shown when Slot Z = Ax
Phasor Screen 2 IA_MAG, IA_ANG, IB_MAG,
IB_ANG, IC_MAG, IC_ANG,
VAB_MAG, VAB_ANG,
VBC_MAG, VBC_ANG,
VCA_MAG, VCA_ANG
Shown when (Slot Z  Ax AND
DELTA_Y = DELTA) AND
(Slot E  70 or L0)
Phasor Screen 3 IA_MAG, IA_ANG, IB_MAG,
IB_ANG, IC_MAG, IC_ANG,
VA_MAG, VA_ANG,
VB_MAG, VB_ANG,
VC_MAG, VC_ANG
Shown when (Slot Z  Ax AND
DELTA_Y = WYE) AND
(Slot E  70 or L0)
