8.37
Date Code 20170927 Instruction Manual SEL-751 Relay
Front-Panel Operations
Touchscreen Display Front Panel
Phasor Screen 4 IA_MAG, IA_ANG, IB_MAG,
IB_ANG, IC_MAG, IC_ANG,
VAB_MAG, VAB_ANG,
VBC_MAG, VBC_ANG,
VCA_MAG, VCA_ANG,
VS_MAG, VS_ANG
Shown when (Slot Z  Ax AND
DELTA_Y = DELTA) AND
(Slot E = 70 or L0)
Phasor Screen 5 IA_MAG, IA_ANG, IB_MAG,
IB_ANG, IC_MAG, IC_ANG,
VA_MAG, VA_ANG,
VB_MAG, VB_ANG,
VC_MAG, VC_ANG,
VS_MAG, VS_ANG
Shown when (Slot Z  Ax AND
DELTA_Y = WYE) AND
(Slot E = 70 or L0)
Fundamental
Fundamental Screen 1 IA_MAG, IA_ANG, IB_MAG,
IB_ANG, IC_MAG, IC_ANG,
IN_MAG, IN_ANG, FREQ,
IG_MAG, IG_ANG, I1_MAG,
I1_ANG, 3I2, IAV, UBI
Shown when Slot Z = Ax
Fundamental Screen 2 IA_MAG, IA_ANG, IB_MAG,
IB_ANG, IC_MAG, IC_ANG,
IN_MAG, IN_ANG, FREQ,
VAB_MAG, VAB_ANG,
VBC_MAG, VBC_ANG,
VCA_MAG, VCA_ANG
Shown when Slot Z  Ax AND
DELTA_Y = DELTA
Fundamental Screen 3 IG_MAG, IG_ANG, I1_MAG,
I1_ANG, 3I2, IAV, UBI,
V1_MAG, V1_ANG, 3V2,
VAVE, UBV
Shown when Slot Z  Ax AND
DELTA_Y = DELTA
Fundamental Screen 4 IA_MAG, IA_ANG, IB_MAG,
IB_ANG, IC_MAG, IC_ANG,
IN_MAG, IN_ANG, FREQ,
VAB_MAG, VAB_ANG,
VBC_MAG, VBC_ANG,
VCA_MAG, VCA_ANG,
VA_MAG, VA_ANG,
VB_MAG, VB_ANG,
VC_MAG, VC_ANG
Shown when Slot Z  Ax AND
DELTA_Y = WYE
Fundamental Screen 5 IG_MAG, IG_ANG, I1_MAG,
I1_ANG, 3I2, IAV, UBI,
VG_MAG, VG_ANG,
V1_MAG, V1_ANG, 3IV2,
VAVE, UBV
Shown when Slot Z  Ax AND
DELTA_Y = WYE
Fundamental Screen 6 P, Q, S, PF Shown when Slot Z  Ax
Fundamental Screen 7 PA, QA, SA, PFA, PB, QB, SB,
PFB, PC, QC, SC, PFC
Shown when Slot Z  Ax and
DELTA_Y = WYE
Fundamental Screen 8 VS, FREQS, VDC Shown when Slot E = 70 or L0
RMS
RMS Screen 1 IARMS, IBRMS, ICRMS,
INRMS
Shown when Slot Z = Ax
RMS Screen 2 IARMS, IBRMS, ICRMS,
INRMS, VABRMS,
VBCRMS, VCARMS
Shown when (Slot Z  Ax AND
DELTA_Y = DELTA) AND
(Slot E  70 or L0)
Table 8.17 Screens Available for the Rotating Display, HOME Pushbutton
a
, and Programmable Pushbuttons
(Sheet 2 of 8)
Home Screen
Folders and
Applications
Folder and
Application
Names
Display Name Quantities Comments
