8.38
SEL-751 Relay Instruction Manual Date Code 20170927
Front-Panel Operations
Touchscreen Display Front Panel
RMS Screen 3 IARMS, IBRMS, ICRMS,
INRMS, VARMS, VBRMS,
VCRMS
Shown when (Slot Z  Ax AND
DELTA_Y = WYE) AND
(Slot E  70 or L0)
RMS Screen 4 IARMS, IBRMS, ICRMS,
INRMS, VABRMS,
VBCRMS, VCARMS,
VSRMS
Shown when (Slot Z  Ax AND
DELTA_Y = DELTA) AND
(Slot E = 70 or L0)
RMS Screen 5 IARMS, IBRMS, ICRMS,
INRMS, VARMS, VBRMS,
VCRMS, VSRMS
Shown when (Slot Z  Ax AND
DELTA_Y = WYE) AND
(Slot E = 70 or L0)
Max/Min
Max/Min Screen 1 IAMX, IAMN, IBMX, IBMN,
ICMX, ICMN, INMX, INMN,
IGMX, IGMN, VABMX,
VAB M N, VAM X , VA M N,
VBCMX, VBCMN, VBMX,
VBMN, VCAMX, VCAMN,
VCMX, VCMN, VSMX,
VSMN, kW3MX, kW3MN,
kVAR3MX, kVAR3MN,
kVA3MX, kVA3MN, FRE-
QMX, FREQMN,
RTD1MX–RTD12MX,
RTD1MN–RTD12MN,
AI301MX–AI308MX,
AI301MN–AI308MN,
AI401MX–AI408MX,
AI401MN–AI408MN,
AI501MX–AI508MX,
AI501MN–AI508MN,
MM_LRD
Voltages, RTD, and analog inputs
are available only when the part
number supports them
Max/Min Reset Screen Reset max/min data Always available
Energy
Energy Screen 1 MWH3PI, MWH3P,
MVARH3PI, MVARH3PO,
MVAH3P, EM_LRD
Available if the relay supports
voltages
Energy Reset Screen Reset energy data
Demand
Demand Screen 1 IAD, IBD, ICD, IGD, 3I2D,
DM_LRD
Always available
Demand Screen 2 KW3DI, KW3DO, KVAR3DI,
KVAR3DO, DM_LRD
Shown when (Slot Z  Ax AND
DELTA_Y=DELTA) or
(Slot Z  Ax AND
DELTA_Y = WYE)
Demand Screen 3 KWADI, KWBDI, KWCDI,
KWADO, KWBDO, KWCDO,
DM_LRD
Shown when Slot Z  Ax AND
DELTA_Y = WYE
Demand Screen 4 KVARADI, KVARBDI,
KVARCDI, KVARADO,
KVARBDO, KVARCDO,
DM_LRD
Shown when Slot Z  Ax AND
DELTA_Y = WYE
Demand Reset Screen Reset demand data Always available
Table 8.17 Screens Available for the Rotating Display, HOME Pushbutton
a
, and Programmable Pushbuttons
(Sheet 3 of 8)
Home Screen
Folders and
Applications
Folder and
Application
Names
Display Name Quantities Comments
