SEL-751 Settings Sheets Date________________
Report Settings (SET R Command) SER Chatter Criteria
SEL-751 Relay Instruction Manual Date Code 20170927
Report Settings (SET R Command)
SER Chatter Criteria
SER Trigger Lists
SERn = As many as 24 Relay Word elements separated by spaces or commas. Use NA to disable the setting.
Relay Word Bit Aliases
ALIASn= 'RW Bit'(space)'Alias'(space)'Asserted Text'(space)'Deasserted Text'. Alias, Asserted, and Deasserted text strings
can be as many as 15 characters long. Use NA to disable setting.
RELAY WORD BIT DLAB17 :=
RELAY WORD BIT DLAB18 :=
RELAY WORD BIT DLAB19 :=
RELAY WORD BIT DLAB20 :=
RELAY WORD BIT DLAB21 :=
RELAY WORD BIT DLAB22 :=
RELAY WORD BIT DLAB23 :=
RELAY WORD BIT DLAB24 :=
RELAY WORD BIT DLAB25 :=
RELAY WORD BIT DLAB26 :=
RELAY WORD BIT DLAB27 :=
RELAY WORD BIT DLAB28 :=
RELAY WORD BIT DLAB29 :=
RELAY WORD BIT DLAB30 :=
RELAY WORD BIT DLAB31 :=
RELAY WORD BIT DLAB32 :=
Auto-Removal Enable (Y, N) ESERDEL :=
Number of Counts (2–20 counts) SRDLCNT :=
Removal Time (0.1–90.0 s) SRDLTIM :=
SER1 :=
SER2 :=
SER3 :=
SER4 :=
Enable ALIAS (N, 1–20) EALIAS :=
ALIAS1 ALIAS1 :=
ALIAS2 ALIAS2 :=
ALIAS3 ALIAS3 :=
ALIAS4 ALIAS4 :=
ALIAS5 ALIAS5 :=
ALIAS6 ALIAS6 :=
ALIAS7 ALIAS7 :=
