Date _______________ SEL-751 Settings Sheets
Event Report Report Settings (SET R Command)
Event Report
HIF Event Reporting
(Hidden if the AST option is not included in the MOT.)
Fast Message Read Settings
FMRnNAM = Any valid string. (No spaces allowed; should be different from other FMRxNAM)
FMRn = As many as 24 analog quantities separated by spaces or commas. (Analog quantities listed here will be included in
the Fast Message read request)
Use NA to disable setting.
ALIAS8 ALIAS8 :=
ALIAS 9 ALIAS9 :=
ALIAS10 ALIAS10 :=
ALIAS11 ALIAS11 :=
ALIAS12 ALIAS12 :=
ALIAS13 ALIAS13 :=
ALIAS14 ALIAS14 :=
ALIAS15 ALIAS15 :=
ALIAS16 ALIAS16 :=
ALIAS17 ALIAS17 :=
ALIAS18 ALIAS18 :=
ALIAS19 ALIAS19 :=
ALIAS20 ALIAS20 :=
EVENT TRIGGER (SELOGIC) ER :=
EVENT LENGTH (15, 64, 180 cyc) LER :=
PREFAULT LENGTH (1–10 cyc {if LER := 15},
1–59 cyc {if LER := 64}, 1–175 cyc {if LER := 180}) PRE :=
HIF EVENT LENGTH (2, 5, 10, 20 min) HIFLER :=
FMR1 Name (9 characters) FMR1NAM :=
Fast Message Read FMR1 (24 analog quantities) FMR1 :=
FMR2 Name (9 characters) FMR2NAM :=
Fast Message Read FMR2 (24 analog quantities) FMR2 :=
FMR3 Name (9 characters) FMR3NAM :=
Fast Message Read FMR3 (24 analog quantities) FMR3 :=
FMR4 Name (9 characters) FMR4NAM :=
Fast Message Read FMR4 (24 analog quantities) FMR4 :=
