8.40
SEL-751 Relay Instruction Manual Date Code 20170927
Front-Panel Operations
Touchscreen Display Front Panel
Remote Analogs Screen 5 RA049–RA060 Always available
Remote Analogs Screen 6 RA061–RA072 Always available
Remote Analogs Screen 7 RA073–RA084 Always available
Remote Analogs Screen 8 RA085–RA096 Always available
Remote Analogs Screen 9 RA097–RA108 Always available
Remote Analogs Screen 10 RA109–RA120 Always available
Remote Analogs Screen 11 RA121–RA128 Always available
Light
Intensity
Light Screen 1 LSENS1, LSENS2, LSENS3,
LSENS4
Shown when Slot E = 70 or L0
Light Screen 2 LSENS1, LSENS2, LSENS3,
LSENS4, LSENS5, LSENS6,
LSENS7, LSENS8
Shown when Slot E = 77
Monitor
Relay Word
Bits
Relay Word Bits Screen 1 Shows status of all the relay
word bits
Shows 32 RWBs per page
Digital
Inputs
Digital Inputs Screen 1 IN101, IN102 Slot A inputs (always available)
Digital Inputs Screen 2 IN301, IN302, IN303, IN304 Shown when Slot C= Dx or
1x or Cx
Digital Inputs Screen 3 IN301, IN302, IN303 Shown when Slot C = Bx
Digital Inputs Screen 4 IN301, IN302, IN303, IN304,
IN305, IN306, IN307, IN308
Shown when Slot C = 3x
Digital Inputs Screen 5 IN301, IN302, IN303, IN304,
IN305, IN306, IN307, IN308,
IN309, IN310, IN311, IN312,
IN313, IN314
Shown when Slot C = 4x
Digital Inputs Screen 6 IN401, IN402, IN403, IN404 Shown when Slot D = Dx or
1x or Cx
Digital Inputs Screen 7 IN401, IN402, IN403 Shown when Slot D = Bx
Digital Inputs Screen 8 IN401, IN402, IN403, IN404,
IN405, IN406, IN407, IN408
Shown when Slot D = 3x
Digital Inputs Screen 9 IN401, IN402, IN403, IN404,
IN405, IN406, IN407, IN408,
IN409, IN410, IN411, IN412,
IN413, IN414
Shown when Slot D = 4x
Digital Inputs Screen 10 IN501, IN502, IN503, IN504 Shown when Slot E = Dx or
1x or Cx
Digital Inputs Screen 11 IN501, IN502, IN503 Shown when Slot E = Bx
Table 8.17 Screens Available for the Rotating Display, HOME Pushbutton
a
, and Programmable Pushbuttons
(Sheet 5 of 8)
Home Screen
Folders and
Applications
Folder and
Application
Names
Display Name Quantities Comments
