8.41
Date Code 20170927 Instruction Manual SEL-751 Relay
Front-Panel Operations
Touchscreen Display Front Panel
Digital Inputs Screen 12 IN501, IN502, IN503, IN504,
IN505, IN506, IN507, IN508
Shown when Slot E = 3x
Digital Inputs Screen 13 IN501, IN502, IN503, IN504,
IN505, IN506, IN507, IN508,
IN509, IN510, IN511, IN512,
IN513, IN514
Shown when Slot E = 4x
Digital
Outputs
Digital Outputs Screen 1 OUT101, OUT102, OUT103 Slot A outputs (always available)
Digital Outputs Screen 2 OUT301, OUT302, OUT303,
OUT304
Shown when Slot C = Bx or
1x or Cx
Digital Outputs Screen 3 OUT301, OUT302, OUT303 Shown when Slot C = Dx
Digital Outputs Screen 4 OUT301, OUT302, OUT303,
OUT304, OUT305, OUT306,
OUT307, OUT308
Shown when Slot C = 2x
Digital Outputs Screen 5 OUT401, OUT402, OUT403,
OUT404
Shown when Slot D = Bx or
1x or Cx
Digital Outputs Screen 6 OUT401, OUT402, OUT403 Shown when Slot D = Dx
Digital Outputs Screen 7 OUT401, OUT402, OUT403,
OUT404, OUT405, OUT406,
OUT407, OUT408
Shown when Slot D = 2x
Digital Outputs Screen 8 OUT501, OUT502, OUT503,
OUT504
Shown when Slot E = Bx or
1x or Cx
Digital Outputs Screen 9 OUT501, OUT502, OUT503 Shown when Slot E = Dx
Digital Outputs Screen 10 OUT501, OUT502, OUT503,
OUT504, OUT505, OUT506,
OUT507, OUT508
Shown when Slot E = 2x
SELOGIC
Counters
SELOGIC Counters Screen 1 SC01–SC32 Shown when ESC  N; shows 12
SEL
OGIC counters per page
Breaker
Wear
Breaker Wear Screen 1 INTT, EXTT, INTIA, INTIB,
INTIC, EXTIA, EXTIB,
EXTIC
Shown when EBMON = Y
Breaker Wear Screen 2 WEARA, WEARB, WEARC,
BR_LRD
Shown when EBMON = Y
Reports
Events
Event History Screen 1 Shows the event records in the
relay
Table 8.17 Screens Available for the Rotating Display, HOME Pushbutton
a
, and Programmable Pushbuttons
(Sheet 6 of 8)
Home Screen
Folders and
Applications
Folder and
Application
Names
Display Name Quantities Comments
