10.14
SEL-751 Relay Instruction Manual Date Code 20170927
Analyzing Events
Event Reporting
PHROT := ABC FNOM := 60 DATE_F := MDY
FAULT := 50G1P OR 50N1P OR 51P1P OR 51QP OR 50Q1P OR TRIP
EMP := N TGR := 3
SS1 := 1
SS2 := 0
SS3 := 0
SS4 := 0
EPMU := N
IRIGC := NONE UTC_OFF := 0.00 DST_BEGM:= OFF
52ABF := N 50BFP := 0.10 BFD := 0.50 ATD := OFF
BFI := R_TRIG TRIP
50PAFP := OFF DCLOP := OFF DCHIP := OFF
IN101D := 10 IN102D := 10
EBMON := Y COSP1 := 10000 COSP2 := 150 COSP3 := 12
KASP1 := 1.20 KASP2 := 8.00 KASP3 := 20.00 BKMON := TRIP
RSTTRGT := 0
RSTENRGY:= 0
RSTMXMN := 0
RSTDEM := 0
RSTPKDEM:= 0
DSABLSET:= 0
TIME_SRC:= IRIG1 TIME_SRC:= IRIG1
Group Settings
RID := SEL-751
TID := FEEDER RELAY
CTR := 120 CTRN := 120 PTR := 180.00 PTRS := 180.00
DELTA_Y := DELTA VSCONN := VS SINGLEV := N VNOM := 120.00
Z1MAG := 2.14 Z1ANG := 68.86 Z0MAG := 6.38 Z0ANG := 72.47
Z0SMAG := 0.36 Z0SANG := 84.61 LL := 4.84 EFLOC := N
50P1P := 10.00 50P1D := 0.00 50P1TC := 1
50P2P := 10.00 50P2D := 0.00 50P2TC := 1
50P3P := 10.00 50P3D := 0.00 50P3TC := 1
50P4P := 10.00 50P4D := 0.00 50P4TC := 1
50N1P := OFF 50N2P := OFF 50N3P := OFF 50N4P := OFF
50G1P := OFF 50G2P := OFF 50G3P := OFF 50G4P := OFF
50Q1P := OFF 50Q2P := OFF 50Q3P := OFF 50Q4P := OFF
51AP := 6.00
51AC := U3 51ATD := 3.00 51ARS := N
51ACT := 0.00 51AMR := 0.00 51ATC := 1
51BP := 6.00 51BC := U3 51BTD := 3.00 51BRS := N
51BCT := 0.00 51BMR := 0.00 51BTC := 1
51CP := 6.00 51CC := U3 51CTD := 3.00 51CRS := N
51CCT := 0.00 51CMR := 0.00 51CTC := 1
51P1P := 6.00 51P1C := U3 51P1TD := 3.00 51P1RS := N
51P1CT := 0.00 51P1MR := 0.00 51P1TC := 1
51P2P := 6.00 51P2C := U3 51P2TD := 3.00 51P2RS := N
51P2CT := 0.00 51P2MR := 0.00 51P2TC := 1
51QP := 6.00 51QC := U3 51QTD := 3.00 51QRS := N
51QCT := 0.00 51QMR := 0.00 51QTC := 1
51N1P := OFF 51N1C := U3 51N1TD := 1.50 51N1RS := N
51N1CT := 0.00 51N1MR := 0.00 51N1TC := 1
51N2P := OFF 51N2C := U3 51N2TD := 1.50 51N2RS := N
51N2CT := 0.00 51N2MR := 0.00 51N2TC := 1
51G1P := 0.50 51G1C := U3 51G1TD := 1.50 51G1RS := N
51G1CT := 0.00 51G1MR := 0.00 51G1TC := 1
51G2P := 0.50 51G2C := U3 51G2TD := 1.50 51G2RS := N
51G2CT := 0.00 51G2MR := 0.00 51G2TC := 1
Figure 10.3 Example Standard 15-Cycle Event Report 1/4-Cycle Resolution (Continued)
