10.15
Date Code 20170927 Instruction Manual SEL-751 Relay
Analyzing Events
Event Reporting
EHBL2 := N EHBL5 := N ELOAD := N
E49RTD := NONE
E49IEC := N
27PP1P := OFF 27PP2P := OFF
27S1P := OFF 27S2P := OFF
59PP1P := OFF 59PP2P := OFF 59Q1P := OFF 59Q2P := OFF
59S1P := OFF 59S2P := OFF
E27I1 := N E27I2 := N
E59I1 := N E59I2 := N E59I3 := N E59I4 := N
E25 := N
LOPBLK := 0
55LGTP := OFF 55LDTP := OFF 55LGAP := OFF 55LDAP := OFF
E78VS := N
81D1TP := OFF
81D2TP := OFF
81D3TP := OFF
81D4TP := OFF
81D5TP := OFF
81D6TP := OFF
E81R := N
E81RF := N EDEM := THM DMTC := 5 PHDEMP := 5.00
GNDEMP := 1.00 3I2DEMP := 1.00
EPWR := N
TDURD := 0.5 CFD := 1.0
TR := ORED50T OR ORED51T OR ORED81T OR REMTRIP OR OC OR SV04T
REMTRIP := 0
ULTRIP := NOT (51P1P OR 51G1P OR 51N1P OR 52A)
52A := 0
CL := SV03T AND LT02 OR CC
ULCL := 0
Report Settings
ESERDEL := N
SER1 := IN101 IN102 51P1T 51G1T 50P1P 50N1T 51N1T PB01 PB02 PB03 PB04
SER2 := CLOSE 52A CC
SER3 := 81D1T 81D2T
SER4 := SALARM
EALIAS := 4
ALIAS1 :=PB01 FP_AUX1 PICKUP DROPOUT
ALIAS2 :=PB02 FP_LOCK PICKUP DROPOUT
ALIAS3 :=PB03 FP_CLOSE PICKUP DROPOUT
ALIAS4 :=PB04 FP_TRIP PICKUP DROPOUT
ER := R_TRIG 51P1P OR R_TRIG 51G1P OR R_TRIG 50P1P OR R_TRIG 50G1P OR R_TRIG 51N1P
OR R_TRIG CF
LER := 15 PRE := 5
FMR1NAM := FMR1
FMR1 :=NA
FMR2NAM := FMR2
FMR2 :=NA
FMR3NAM := FMR3
FMR3 :=NA
FMR4NAM := FMR4
FMR4 :=NA
RA01TYPE:= I
RA02TYPE:= I
RA03TYPE:= I
RA04TYPE:= I
RA05TYPE:= I
RA06TYPE:= I
RA07TYPE:= I
RA08TYPE:= I
RA09TYPE:= I
RA10TYPE:= I
RA11TYPE:= I
RA12TYPE:= I
RA13TYPE:= I
RA14TYPE:= I
RA15TYPE:= I
RA16TYPE:= I
RA17TYPE:= I
Figure 10.3 Example Standard 15-Cycle Event Report 1/4-Cycle Resolution (Continued)
