Schweitzer Engineering Laboratories SEL-751 - Page 751

E.37
Date Code 20170927 Instruction Manual SEL-751 Relay
Modbus RTU Communications
Communications Protocol
793 (R/W) RA077 (1:LW) -32768 32767 0 0.01 893
794 (R/W) RA078 (0:UW) -32768 32767 0 0.01 894
795 (R/W) RA078 (1:LW) -32768 32767 0 0.01 895
796 (R/W) RA079 (0:UW) -32768 32767 0 0.01 896
797 (R/W) RA079 (1:LW) -32768 32767 0 0.01 897
798 (R/W) RA080 (0:UW) -32768 32767 0 0.01 898
799 (R/W) RA080 (1:LW) -32768 32767 0 0.01 899
800 (R/W) RA081 (0:UW) -32768 32767 0 0.01 900
801 (R/W) RA081 (1:LW) -32768 32767 0 0.01 901
802 (R/W) RA082 (0:UW) -32768 32767 0 0.01 902
803 (R/W) RA082 (1:LW) -32768 32767 0 0.01 903
804 (R/W) RA083 (0:UW) -32768 32767 0 0.01 904
805 (R/W) RA083 (1:LW) -32768 32767 0 0.01 905
806 (R/W) RA084 (0:UW) -32768 32767 0 0.01 906
807 (R/W) RA084 (1:LW) -32768 32767 0 0.01 907
808 (R/W) RA085 (0:UW) -32768 32767 0 0.01 908
809 (R/W) RA085 (1:LW) -32768 32767 0 0.01 909
810 (R/W) RA086 (0:UW) -32768 32767 0 0.01 910
811 (R/W) RA086 (1:LW) -32768 32767 0 0.01 911
812 (R/W) RA087 (0:UW) -32768 32767 0 0.01 912
813 (R/W) RA087 (1:LW) -32768 32767 0 0.01 913
814 (R/W) RA088 (0:UW) -32768 32767 0 0.01 914
815 (R/W) RA088 (1:LW) -32768 32767 0 0.01 915
816 (R/W) RA089 (0:UW) -32768 32767 0 0.01 916
817 (R/W) RA089 (1:LW) -32768 32767 0 0.01 917
818 (R/W) RA090 (0:UW) -32768 32767 0 0.01 918
819 (R/W) RA090 (1:LW) -32768 32767 0 0.01 919
820 (R/W) RA091 (0:UW) -32768 32767 0 0.01 920
821 (R/W) RA091 (1:LW) -32768 32767 0 0.01 921
822 (R/W) RA092 (0:UW) -32768 32767 0 0.01 922
823 (R/W) RA092 (1:LW) -32768 32767 0 0.01 923
824 (R/W) RA093 (0:UW) -32768 32767 0 0.01 924
825 (R/W) RA093 (1:LW) -32768 32767 0 0.01 925
826 (R/W) RA094 (0:UW) -32768 32767 0 0.01 926
827 (R/W) RA094 (1:LW) -32768 32767 0 0.01 927
828 (R/W) RA095 (0:UW) -32768 32767 0 0.01 928
829 (R/W) RA095 (1:LW) -32768 32767 0 0.01 929
830 (R/W) RA096 (0:UW) -32768 32767 0 0.01 930
831 (R/W) RA096 (1:LW) -32768 32767 0 0.01 931
832 (R/W) RA097 (0:UW) -32768 32767 0 0.01 932
833 (R/W) RA097 (1:LW) -32768 32767 0 0.01 933
834 (R/W) RA098 (0:UW) -32768 32767 0 0.01 934
835 (R/W) RA098 (1:LW) -32768 32767 0 0.01 935
836 (R/W) RA099 (0:UW) -32768 32767 0 0.01 936
837 (R/W) RA099 (1:LW) -32768 32767 0 0.01 937
Table E.34 Modbus Register Map
a
(Sheet 13 of 38)
Modbus Register
Address
b
Name/Enums Units Min Max Default
Scale
Fac to r
DeviceNet
Parameter
Numbers
