Schweitzer Engineering Laboratories SEL-751 - Page 756

E.42
SEL-751 Relay Instruction Manual Date Code 20170927
Modbus RTU Communications
Communications Protocol
1018 (R) VS MAX DAY yy 2000 9999 2000 1 1118
1019 (R) VS MIN kV 0 65535 0 1 1119
1020 (R) VS MIN TIME ss 0 5999 0 0.01 1120
1021 (R) VS MIN TIME mm 0 59 0 1 1121
1022 (R) VS MIN TIME hh 0 23 0 1 1122
1023 (R) VS MIN DAY dd 1 31 1 1 1123
1024 (R) VS MIN DAY mm 1 12 1 1 1124
1025 (R) VS MIN DAY yy 2000 9999 2000 1 1125
1026 (R) KW3P MAX kW -32768 32767 0 1 1126
1027 (R) KW3P MX TIM ss 0 5999 0 0.01 1127
1028 (R) KW3P MX TIM mm 0 59 0 1 1128
1029 (R) KW3P MX TIM hh 0 23 0 1 1129
1030 (R) KW3P MX DAY dd 1 31 1 1 1130
1031 (R) KW3P MX DAY mm 1 12 1 1 1131
1032 (R) KW3P MX DAY yy 2000 9999 2000 1 1132
1033 (R) KW3P MIN kW -32768 32767 0 1 1133
1034 (R) KW3P MN TIM ss 0 5999 0 0.01 1134
1035 (R) KW3P MN TIM mm 0 59 0 1 1135
1036 (R) KW3P MN TIM hh 0 23 0 1 1136
1037 (R) KW3P MN DAY dd 1 31 1 1 1137
1038 (R) KW3P MN DAY mm 1 12 1 1 1138
1039 (R) KW3P MN DAY yy 2000 9999 2000 1 1139
1040 (R) KVAR3P MAX kVAR -32768 32767 0 1 1140
1041 (R) KVAR3P MX TIM ss 0 5999 0 0.01 1141
1042 (R) KVAR3P MX TIM mm 0 59 0 1 1142
1043 (R) KVAR3P MX TIM hh 0 23 0 1 1143
1044 (R) KVAR3P MX DAY dd 1 31 1 1 1144
1045 (R) KVAR3P MX DAY mm 1 12 1 1 1145
1046 (R) KVAR3P MX DAY yy 2000 9999 2000 1 1146
1047 (R) KVAR3P MIN kVAR -32768 32767 0 1 1147
1048 (R) KVAR3P MN TIM ss 0 5999 0 0.01 1148
1049 (R) KVAR3P MN TIM mm 0 59 0 1 1149
1050 (R) KVAR3P MN TIM hh 0 23 0 1 1150
1051 (R) KVAR3P MN DAY dd 1 31 1 1 1151
1052 (R) KVAR3P MN DAY mm 1 12 1 1 1152
1053 (R) KVAR3P MN DAY yy 2000 9999 2000 1 1153
1054 (R) KVA3P MAX kVA -32768 32767 0 1 1154
1055 (R) KVA3P MX TIM ss 0 5999 0 0.01 1155
1056 (R) KVA3P MX TIM mm 0 59 0 1 1156
1057 (R) KVA3P MX TIM hh 0 23 0 1 1157
1058 (R) KVA3P MX DAY dd 1 31 1 1 1158
1059 (R) KVA3P MX DAY mm 1 12 1 1 1159
1060 (R) KVA3P MX DAY yy 2000 9999 2000 1 1160
1061 (R) KVA3P MIN kVA -32768 32767 0 1 1161
1062 (R) KVA3P MN TIM ss 0 5999 0 0.01 1162
Table E.34 Modbus Register Map
a
(Sheet 18 of 38)
Modbus Register
Address
b
Name/Enums Units Min Max Default
Scale
Fac to r
DeviceNet
Parameter
Numbers
