Modbus RTU Communications
Communications Protocol
1063 (R) KVA3P MN TIM mm 0 59 0 1 1163
1064 (R) KVA3P MN TIM hh 0 23 0 1 1164
1065 (R) KVA3P MN DAY dd 1 31 1 1 1165
1066 (R) KVA3P MN DAY mm 1 12 1 1 1166
1067 (R) KVA3P MN DAY yy 2000 9999 2000 1 1167
1068 (R) FREQ MAX Hz 0 65535 0 0.01 1168
1069 (R) FREQ MX TIM ss 0 5999 0 0.01 1169
1070 (R) FREQ MX TIM mm 0 59 0 1 1170
1071 (R) FREQ MX TIM hh 0 23 0 1 1171
1072 (R) FREQ MX DAY dd 1 31 1 1 1172
1073 (R) FREQ MX DAY mm 1 12 1 1 1173
1074 (R) FREQ MX DAY yy 2000 9999 2000 1 1174
1075 (R) FREQ MIN Hz 0 65535 0 0.01 1175
1076 (R) FREQ MN TIM ss 0 5999 0 0.01 1176
1077 (R) FREQ MN TIM mm 0 59 0 1 1177
1078 (R) FREQ MN TIM hh 0 23 0 1 1178
1079 (R) FREQ MN DAY dd 1 31 1 1 1179
1080 (R) FREQ MN DAY mm 1 12 1 1 1180
1081 (R) FREQ MN DAY yy 2000 9999 2000 1 1181
1082–1089 (R) Reserved
c
1182–1189
MAX/MIN RTD Data
1090 (R) RTD1 MAX °C -32768 32767 0 1 1190
1091 (R) RTD1 MX TIM ss 0 5999 0 0.01 1191
1092 (R) RTD1 MX TIM mm 0 59 0 1 1192
1093 (R) RTD1 MX TIM hh 0 23 0 1 1193
1094 (R) RTD1 MX DAY dd 1 31 1 1 1194
1095 (R) RTD1 MX DAY mm 1 12 1 1 1195
1096 (R) RTD1 MX DAY yy 2000 9999 2000 1 1196
1097 (R) RTD1 MIN
°C -32768 32767 0 1 1197
1098 (R) RTD1 MN TIM ss 0 5999 0 0.01 1198
1099 (R) RTD1 MN TIM mm 0 59 0 1 1199
1100 (R) RTD1 MN TIM hh 0 23 0 1 1200
1101 (R) RTD1 MN DAY dd 1 31 1 1 1201
1102 (R) RTD1 MN DAY mm 1 12 1 1 1202
1103 (R) RTD1 MN DAY yy 2000 9999 2000 1 1203
1104 (R) RTD2 MAX
°C -32768 32767 0 1 1204
1105 (R) RTD2 MX TIM ss 0 5999 0 0.01 1205
1106 (R) RTD2 MX TIM mm 0 59 0 1 1206
1107 (R) RTD2 MX TIM hh 0 23 0 1 1207
1108 (R) RTD2 MX DAY dd 1 31 1 1 1208
1109 (R) RTD2 MX DAY mm 1 12 1 1 1209
1110 (R) RTD2 MX DAY yy 2000 9999 2000 1 1210
1111 (R) RTD2 MIN
°C -32768 32767 0 1 1211
1112 (R) RTD2 MN TIM ss 0 5999 0 0.01 1212
1113 (R) RTD2 MN TIM mm 0 59 0 1 1213
Table E.34 Modbus Register Map
a
(Sheet 19 of 38)
Modbus Register
Address
b
Name/Enums Units Min Max Default
Scale
Fac to r
DeviceNet
Parameter
Numbers
