Schweitzer Engineering Laboratories SEL-751 - Page 759

E.45
Date Code 20170927 Instruction Manual SEL-751 Relay
Modbus RTU Communications
Communications Protocol
1159 (R) RTD5 MN DAY yy 2000 9999 2000 1 1259
1160 (R) RTD6 MAX
°C -32768 32767 0 1 1260
1161 (R) RTD6 MX TIM ss 0 5999 0 0.01 1261
1162 (R) RTD6 MX TIM mm 0 59 0 1 1262
1163 (R) RTD6 MX TIM hh 0 23 0 1 1263
1164 (R) RTD6 MX DAY dd 1 31 1 1 1264
1165 (R) RTD6 MX DAY mm 1 12 1 1 1265
1166 (R) RTD6 MX DAY yy 2000 9999 2000 1 1266
1167 (R) RTD6 MIN
°C -32768 32767 0 1 1267
1168 (R) RTD6 MN TIM ss 0 5999 0 0.01 1268
1169 (R) RTD6 MN TIM mm 0 59 0 1 1269
1170 (R) RTD6 MN TIM hh 0 23 0 1 1270
1171 (R) RTD6 MN DAY dd 1 31 1 1 1271
1172 (R) RTD6 MN DAY mm 1 12 1 1 1272
1173 (R) RTD6 MN DAY yy 2000 9999 2000 1 1273
1174 (R) RTD7 MAX
°C -32768 32767 0 1 1274
1175 (R) RTD7 MX TIM ss 0 5999 0 0.01 1275
1176 (R) RTD7 MX TIM mm 0 59 0 1 1276
1177 (R) RTD7 MX TIM hh 0 23 0 1 1277
1178 (R) RTD7 MX DAY dd 1 31 1 1 1278
1179 (R) RTD7 MX DAY mm 1 12 1 1 1279
1180 (R) RTD7 MX DAY yy 2000 9999 2000 1 1280
1181 (R) RTD7 MIN
°C -32768 32767 0 1 1281
1182 (R) RTD7 MN TIM ss 0 5999 0 0.01 1282
1183 (R) RTD7 MN TIM mm 0 59 0 1 1283
1184 (R) RTD7 MN TIM hh 0 23 0 1 1284
1185 (R) RTD7 MN DAY dd 1 31 1 1 1285
1186 (R) RTD7 MN DAY mm 1 12 1 1 1286
1187 (R) RTD7 MN DAY yy 2000 9999 2000 1 1287
1188 (R) RTD8 MAX
°C -32768 32767 0 1 1288
1189 (R) RTD8 MX TIM ss 0 5999 0 0.01 1289
1190 (R) RTD8 MX TIM mm 0 59 0 1 1290
1191 (R) RTD8 MX TIM hh 0 23 0 1 1291
1192 (R) RTD8 MX DAY dd 1 31 1 1 1292
1193 (R) RTD8 MX DAY mm 1 12 1 1 1293
1194 (R) RTD8 MX DAY yy 2000 9999 2000 1 1294
1195 (R) RTD8 MIN
°C -32768 32767 0 1 1295
1196 (R) RTD8 MN TIM ss 0 5999 0 0.01 1296
1197 (R) RTD8 MN TIM mm 0 59 0 1 1297
1198 (R) RTD8 MN TIM hh 0 23 0 1 1298
1199 (R) RTD8 MN DAY dd 1 31 1 1 1299
1200 (R) RTD8 MN DAY mm 1 12 1 1 1300
1201 (R) RTD8 MN DAY yy 2000 9999 2000 1 1301
1202 (R) RTD9 MAX
°C -32768 32767 0 1 1302
1203 (R) RTD9 MX TIM ss 0 5999 0 0.01 1303
Table E.34 Modbus Register Map
a
(Sheet 21 of 38)
Modbus Register
Address
b
Name/Enums Units Min Max Default
Scale
Fac to r
DeviceNet
Parameter
Numbers
