E.46
SEL-751 Relay Instruction Manual Date Code 20170927
Modbus RTU Communications
Communications Protocol
1204 (R) RTD9 MX TIM mm 0 59 0 1 1304
1205 (R) RTD9 MX TIM hh 0 23 0 1 1305
1206 (R) RTD9 MX DAY dd 1 31 1 1 1306
1207 (R) RTD9 MX DAY mm 1 12 1 1 1307
1208 (R) RTD9 MX DAY yy 2000 9999 2000 1 1308
1209 (R) RTD9 MIN
°C -32768 32767 0 1 1309
1210 (R) RTD9 MN TIM ss 0 5999 0 0.01 1310
1211 (R) RTD9 MN TIM mm 0 59 0 1 1311
1212 (R) RTD9 MN TIM hh 0 23 0 1 1312
1213 (R) RTD9 MN DAY dd 1 31 1 1 1313
1214 (R) RTD9 MN DAY mm 1 12 1 1 1314
1215 (R) RTD9 MN DAY yy 2000 9999 2000 1 1315
1216 (R) RTD10 MAX
°C -32768 32767 0 1 1316
1217 (R) RTD10 MX TIM ss 0 5999 0 0.01 1317
1218 (R) RTD10 MX TIM mm 0 59 0 1 1318
1219 (R) RTD10 MX TIM hh 0 23 0 1 1319
1220 (R) RTD10 MX DAY dd 1 31 1 1 1320
1221 (R) RTD10 MX DAY mm 1 12 1 1 1321
1222 (R) RTD10 MX DAY yy 2000 9999 2000 1 1322
1223 (R) RTD10 MIN
°C -32768 32767 0 1 1323
1224 (R) RTD10 MN TIM ss 0 5999 0 0.01 1324
1225 (R) RTD10 MN TIM mm 0 59 0 1 1325
1226 (R) RTD10 MN TIM hh 0 23 0 1 1326
1227 (R) RTD10 MN DAY dd 1 31 1 1 1327
1228 (R) RTD10 MN DAY mm 1 12 1 1 1328
1229 (R) RTD10 MN DAY yy 2000 9999 2000 1 1329
1230 (R) RTD11 MAX
°C -32768 32767 0 1 1330
1231 (R) RTD11 MX TIM ss 0 5999 0 0.01 1331
1232 (R) RTD11 MX TIM mm 0 59 0 1 1332
1233 (R) RTD11 MX TIM hh 0 23 0 1 1333
1234 (R) RTD11 MX DAY dd 1 31 1 1 1334
1235 (R) RTD11 MX DAY mm 1 12 1 1 1335
1236 (R) RTD11 MX DAY yy 2000 9999 2000 1 1336
1237 (R) RTD11 MIN
°C -32768 32767 0 1 1337
1238 (R) RTD11 MN TIM ss 0 5999 0 0.01 1338
1239 (R) RTD11 MN TIM mm 0 59 0 1 1339
1240 (R) RTD11 MN TIM hh 0 23 0 1 1340
1241 (R) RTD11 MN DAY dd 1 31 1 1 1341
1242 (R) RTD11 MN DAY mm 1 12 1 1 1342
1243 (R) RTD11 MN DAY yy 2000 9999 2000 1 1343
1244 (R) RTD12 MAX
°C -32768 32767 0 1 1344
1245 (R) RTD12 MX TIM ss 0 5999 0 0.01 1345
1246 (R) RTD12 MX TIM mm 0 59 0 1 1346
1247 (R) RTD12 MX TIM hh 0 23 0 1 1347
1248 (R) RTD12 MX DAY dd 1 31 1 1 1348
Table E.34 Modbus Register Map
a
(Sheet 22 of 38)
Modbus Register
Address
b
Name/Enums Units Min Max Default
Scale
Fac to r
DeviceNet
Parameter
Numbers
