E.48
SEL-751 Relay Instruction Manual Date Code 20170927
Modbus RTU Communications
Communications Protocol
1304 (R) AI303 MX TIM ss 0 5999 0 0.01 1404
1305 (R) AI303 MX TIM mm 0 59 0 1 1405
1306 (R) AI303 MX TIM hh 0 23 0 1 1406
1307 (R) AI303 MX DAY dd 1 31 1 1 1407
1308 (R) AI303 MX DAY mm 1 12 1 1 1408
1309 (R) AI303 MX DAY yy 2000 9999 2000 1 1409
1310 (R) AI303 MN - HI EU -32768 32767 0 0.001 1410
1311 (R) AI303 MN - LO EU -32768 32767 0 0.001 1411
1312 (R) AI303 MN TIM ss 0 5999 0 0.01 1412
1313 (R) AI303 MN TIM mm 0 59 0 1 1413
1314 (R) AI303 MN TIM hh 0 23 0 1 1414
1315 (R) AI303 MN DAY dd 1 31 1 1 1415
1316 (R) AI303 MN DAY mm 1 12 1 1 1416
1317 (R) AI303 MN DAY yy 2000 9999 2000 1 1417
1318 (R) AI304 MX - HI EU -32768 32767 0 0.001 1418
1319 (R) AI304 MX - LO EU -32768 32767 0 0.001 1419
1320 (R) AI304 MX TIM ss 0 5999 0 0.01 1420
1321 (R) AI304 MX TIM mm 0 59 0 1 1421
1322 (R) AI304 MX TIM hh 0 23 0 1 1422
1323 (R) AI304 MX DAY dd 1 31 1 1 1423
1324 (R) AI304 MX DAY mm 1 12 1 1 1424
1325 (R) AI304 MX DAY yy 2000 9999 2000 1 1425
1326 (R) AI304 MN - HI EU -32768 32767 0 0.001 1426
1327 (R) AI304 MN - LO EU -32768 32767 0 0.001 1427
1328 (R) AI304 MN TIM ss 0 5999 0 0.01 1428
1329 (R) AI304 MN TIM mm 0 59 0 1 1429
1330 (R) AI304 MN TIM hh 0 23 0 1 1430
1331 (R) AI304 MN DAY dd 1 31 1 1 1431
1332 (R) AI304 MN DAY mm 1 12 1 1 1432
1333 (R) AI304 MN DAY yy 2000 9999 2000 1 1433
1334 (R) AI305 MX - HI EU -32768 32767 0 0.001 1434
1335 (R) AI305 MX - LO EU -32768 32767 0 0.001 1435
1336 (R) AI305 MX TIM ss 0 5999 0 0.01 1436
1337 (R) AI305 MX TIM mm 0 59 0 1 1437
1338 (R) AI305 MX TIM hh 0 23 0 1 1438
1339 (R) AI305 MX DAY dd 1 31 1 1 1439
1340 (R) AI305 MX DAY mm 1 12 1 1 1440
1341 (R) AI305 MX DAY yy 2000 9999 2000 1 1441
1342 (R) AI305 MN - HI EU -32768 32767 0 0.001 1442
1343 (R) AI305 MN - LO EU -32768 32767 0 0.001 1443
1344 (R) AI305 MN TIM ss 0 5999 0 0.01 1444
1345 (R) AI305 MN TIM mm 0 59 0 1 1445
1346 (R) AI305 MN TIM hh 0 23 0 1 1446
1347 (R) AI305 MN DAY dd 1 31 1 1 1447
1348 (R) AI305 MN DAY mm 1 12 1 1 1448
Table E.34 Modbus Register Map
a
(Sheet 24 of 38)
Modbus Register
Address
b
Name/Enums Units Min Max Default
Scale
Fac to r
DeviceNet
Parameter
Numbers
