Schweitzer Engineering Laboratories SEL-751 - Page 763

E.49
Date Code 20170927 Instruction Manual SEL-751 Relay
Modbus RTU Communications
Communications Protocol
1349 (R) AI305 MN DAY yy 2000 9999 2000 1 1449
1350 (R) AI306 MX - HI EU -32768 32767 0 0.001 1450
1351 (R) AI306 MX - LO EU -32768 32767 0 0.001 1451
1352 (R) AI306 MX TIM ss 0 5999 0 0.01 1452
1353 (R) AI306 MX TIM mm 0 59 0 1 1453
1354 (R) AI306 MX TIM hh 0 23 0 1 1454
1355 (R) AI306 MX DAY dd 1 31 1 1 1455
1356 (R) AI306 MX DAY mm 1 12 1 1 1456
1357 (R) AI306 MX DAY yy 2000 9999 2000 1 1457
1358 (R) AI306 MN - HI EU -32768 32767 0 0.001 1458
1359 (R) AI306 MN - LO EU -32768 32767 0 0.001 1459
1360 (R) AI306 MN TIM ss 0 5999 0 0.01 1460
1361 (R) AI306 MN TIM mm 0 59 0 1 1461
1362 (R) AI306 MN TIM hh 0 23 0 1 1462
1363 (R) AI306 MN DAY dd 1 31 1 1 1463
1364 (R) AI306 MN DAY mm 1 12 1 1 1464
1365 (R) AI306 MN DAY yy 2000 9999 2000 1 1465
1366 (R) AI307 MX - HI EU -32768 32767 0 0.001 1466
1367 (R) AI307 MX - LO EU -32768 32767 0 0.001 1467
1368 (R) AI307 MX TIM ss 0 5999 0 0.01 1468
1369 (R) AI307 MX TIM mm 0 59 0 1 1469
1370 (R) AI307 MX TIM hh 0 23 0 1 1470
1371 (R) AI307 MX DAY dd 1 31 1 1 1471
1372 (R) AI307 MX DAY mm 1 12 1 1 1472
1373 (R) AI307 MX DAY yy 2000 9999 2000 1 1473
1374 (R) AI307 MN - HI EU -32768 32767 0 0.001 1474
1375 (R) AI307 MN - LO EU -32768 32767 0 0.001 1475
1376 (R) AI307 MN TIM ss 0 5999 0 0.01 1476
1377 (R) AI307 MN TIM mm 0 59 0 1 1477
1378 (R) AI307 MN TIM hh 0 23 0 1 1478
1379 (R) AI307 MN DAY dd 1 31 1 1 1479
1380 (R) AI307 MN DAY mm 1 12 1 1 1480
1381 (R) AI307 MN DAY yy 2000 9999 2000 1 1481
1382 (R) AI308 MX - HI EU -32768 32767 0 0.001 1482
1383 (R) AI308 MX - LO EU -32768 32767 0 0.001 1483
1384 (R) AI308 MX TIM ss 0 5999 0 0.01 1484
1385 (R) AI308 MX TIM mm 0 59 0 1 1485
1386 (R) AI308 MX TIM hh 0 23 0 1 1486
1387 (R) AI308 MX DAY dd 1 31 1 1 1487
1388 (R) AI308 MX DAY mm 1 12 1 1 1488
1389 (R) AI308 MX DAY yy 2000 9999 2000 1 1489
1390 (R) AI308 MN - HI EU -32768 32767 0 0.001 1490
1391 (R) AI308 MN - LO EU -32768 32767 0 0.001 1491
Table E.34 Modbus Register Map
a
(Sheet 25 of 38)
Modbus Register
Address
b
Name/Enums Units Min Max Default
Scale
Fac to r
DeviceNet
Parameter
Numbers
