Schweitzer Engineering Laboratories SEL-751 - Page 765

E.51
Date Code 20170927 Instruction Manual SEL-751 Relay
Modbus RTU Communications
Communications Protocol
1435 (R) AI403 MX DAY dd 1 31 1 1 1535
1436 (R) AI403 MX DAY mm 1 12 1 1 1536
1437 (R) AI403 MX DAY yy 2000 9999 2000 1 1537
1438 (R) AI403 MN - HI EU -32768 32767 0 0.001 1538
1439 (R) AI403 MN - LO EU -32768 32767 0 0.001 1539
1440 (R) AI403 MN TIM ss 0 5999 0 0.01 1540
1441 (R) AI403 MN TIM mm 0 59 0 1 1541
1442 (R) AI403 MN TIM hh 0 23 0 1 1542
1443 (R) AI403 MN DAY dd 1 31 1 1 1543
1444 (R) AI403 MN DAY mm 1 12 1 1 1544
1445 (R) AI403 MN DAY yy 2000 9999 2000 1 1545
1446 (R) AI404 MX - HI EU -32768 32767 0 0.001 1546
1447 (R) AI404 MX - LO EU -32768 32767 0 0.001 1547
1448 (R) AI404 MX TIM ss 0 5999 0 0.01 1548
1449 (R) AI404 MX TIM mm 0 59 0 1 1549
1450 (R) AI404 MX TIM hh 0 23 0 1 1550
1451 (R) AI404 MX DAY dd 1 31 1 1 1551
1452 (R) AI404 MX DAY mm 1 12 1 1 1552
1453 (R) AI404 MX DAY yy 2000 9999 2000 1 1553
1454 (R) AI404 MN - HI EU -32768 32767 0 0.001 1554
1455 (R) AI404 MN - LO EU -32768 32767 0 0.001 1555
1456 (R) AI404 MN TIM ss 0 5999 0 0.01 1556
1457 (R) AI404 MN TIM mm 0 59 0 1 1557
1458 (R) AI404 MN TIM hh 0 23 0 1 1558
1459 (R) AI404 MN DAY dd 1 31 1 1 1559
1460 (R) AI404 MN DAY mm 1 12 1 1 1560
1461 (R) AI404 MN DAY yy 2000 9999 2000 1 1561
1462 (R) AI405 MX - HI EU -32768 32767 0 0.001 1562
1463 (R) AI405 MX - LO EU -32768 32767 0 0.001 1563
1464 (R) AI405 MX TIM ss 0 5999 0 0.01 1564
1465 (R) AI405 MX TIM mm 0 59 0 1 1565
1466 (R) AI405 MX TIM hh 0 23 0 1 1566
1467 (R) AI405 MX DAY dd 1 31 1 1 1567
1468 (R) AI405 MX DAY mm 1 12 1 1 1568
1469 (R) AI405 MX DAY yy 2000 9999 2000 1 1569
1470 (R) AI405 MN - HI EU -32768 32767 0 0.001 1570
1471 (R) AI405 MN - LO EU -32768 32767 0 0.001 1571
1472 (R) AI405 MN TIM ss 0 5999 0 0.01 1572
1473 (R) AI405 MN TIM mm 0 59 0 1 1573
1474 (R) AI405 MN TIM hh 0 23 0 1 1574
1475 (R) AI405 MN DAY dd 1 31 1 1 1575
1476 (R) AI405 MN DAY mm 1 12 1 1 1576
1477 (R) AI405 MN DAY yy 2000 9999 2000 1 1577
1478 (R) AI406 MX - HI EU -32768 32767 0 0.001 1578
1479 (R) AI406 MX - LO EU -32768 32767 0 0.001 1579
Table E.34 Modbus Register Map
a
(Sheet 27 of 38)
Modbus Register
Address
b
Name/Enums Units Min Max Default
Scale
Fac to r
DeviceNet
Parameter
Numbers
