E.52
SEL-751 Relay Instruction Manual Date Code 20170927
Modbus RTU Communications
Communications Protocol
1480 (R) AI406 MX TIM ss 0 5999 0 0.01 1580
1481 (R) AI406 MX TIM mm 0 59 0 1 1581
1482 (R) AI406 MX TIM hh 0 23 0 1 1582
1483 (R) AI406 MX DAY dd 1 31 1 1 1583
1484 (R) AI406 MX DAY mm 1 12 1 1 1584
1485 (R) AI406 MX DAY yy 2000 9999 2000 1 1585
1486 (R) AI406 MN - HI EU -32768 32767 0 0.001 1586
1487 (R) AI406 MN - LO EU -32768 32767 0 0.001 1587
1488 (R) AI406 MN TIM ss 0 5999 0 0.01 1588
1489 (R) AI406 MN TIM mm 0 59 0 1 1589
1490 (R) AI406 MN TIM hh 0 23 0 1 1590
1491 (R) AI406 MN DAY dd 1 31 1 1 1591
1492 (R) AI406 MN DAY mm 1 12 1 1 1592
1493 (R) AI406 MN DAY yy 2000 9999 2000 1 1593
1494 (R) AI407 MX - HI EU -32768 32767 0 0.001 1594
1495 (R) AI407 MX - LO EU -32768 32767 0 0.001 1595
1496 (R) AI407 MX TIM ss 0 5999 0 0.01 1596
1497 (R) AI407 MX TIM mm 0 59 0 1 1597
1498 (R) AI407 MX TIM hh 0 23 0 1 1598
1499 (R) AI407 MX DAY dd 1 31 1 1 1599
1500 (R) AI407 MX DAY mm 1 12 1 1 1600
1501 (R) AI407 MX DAY yy 2000 9999 2000 1 1601
1502 (R) AI407 MN - HI EU -32768 32767 0 0.001 1602
1503 (R) AI407 MN - LO EU -32768 32767 0 0.001 1603
1504 (R) AI407 MN TIM ss 0 5999 0 0.01 1604
1505 (R) AI407 MN TIM mm 0 59 0 1 1605
1506 (R) AI407 MN TIM hh 0 23 0 1 1606
1507 (R) AI407 MN DAY dd 1 31 1 1 1607
1508 (R) AI407 MN DAY mm 1 12 1 1 1608
1509 (R) AI407 MN DAY yy 2000 9999 2000 1 1609
1510 (R) AI408 MX - HI EU -32768 32767 0 0.001 1610
1511 (R) AI408 MX - LO EU -32768 32767 0 0.001 1611
1512 (R) AI408 MX TIM ss 0 5999 0 0.01 1612
1513 (R) AI408 MX TIM mm 0 59 0 1 1613
1514 (R) AI408 MX TIM hh 0 23 0 1 1614
1515 (R) AI408 MX DAY dd 1 31 1 1 1615
1516 (R) AI408 MX DAY mm 1 12 1 1 1616
1517 (R) AI408 MX DAY yy 2000 9999 2000 1 1617
1518 (R) AI408 MN - HI EU -32768 32767 0 0.001 1618
1519 (R) AI408 MN - LO EU -32768 32767 0 0.001 1619
1520 (R) AI408 MN TIM ss 0 5999 0 0.01 1620
1521 (R) AI408 MN TIM mm 0 59 0 1 1621
1522 (R) AI408 MN TIM hh 0 23 0 1 1622
Table E.34 Modbus Register Map
a
(Sheet 28 of 38)
Modbus Register
Address
b
Name/Enums Units Min Max Default
Scale
Fac to r
DeviceNet
Parameter
Numbers
