E.53
Date Code 20170927 Instruction Manual SEL-751 Relay
Modbus RTU Communications
Communications Protocol
1523 (R) AI408 MN DAY dd 1 31 1 1 1623
1524 (R) AI408 MN DAY mm 1 12 1 1 1624
1525 (R) AI408 MN DAY yy 2000 9999 2000 1 1625
MAX/MIN AI5 Data
1526 (R) AI501 MX - HI EU -32768 32767 0 0.001 1626
1527 (R) AI501 MX - LO EU -32768 32767 0 0.001 1627
1528 (R) AI501 MX TIM ss 0 5999 0 0.01 1628
1529 (R) AI501 MX TIM mm 0 59 0 1 1629
1530 (R) AI501 MX TIM hh 0 23 0 1 1630
1531 (R) AI501 MX DAY dd 1 31 1 1 1631
1532 (R) AI501 MX DAY mm 1 12 1 1 1632
1533 (R) AI501 MX DAY yy 2000 9999 2000 1 1633
1534 (R) AI501 MN - HI EU -32768 32767 0 0.001 1634
1535 (R) AI501 MN - LO EU -32768 32767 0 0.001 1635
1536 (R) AI501 MN TIM ss 0 5999 0 0.01 1636
1537 (R) AI501 MN TIM mm 0 59 0 1 1637
1538 (R) AI501 MN TIM hh 0 23 0 1 1638
1539 (R) AI501 MN DAY dd 1 31 1 1 1639
1540 (R) AI501 MN DAY mm 1 12 1 1 1640
1541 (R) AI501 MN DAY yy 2000 9999 2000 1 1641
1542 (R) AI502 MX - HI EU -32768 32767 0 0.001 1642
1543 (R) AI502 MX - LO EU -32768 32767 0 0.001 1643
1544 (R) AI502 MX TIM ss 0 5999 0 0.01 1644
1545 (R) AI502 MX TIM mm 0 59 0 1 1645
1546 (R) AI502 MX TIM hh 0 23 0 1 1646
1547 (R) AI502 MX DAY dd 1 31 1 1 1647
1548 (R) AI502 MX DAY mm 1 12 1 1 1648
1549 (R) AI502 MX DAY yy 2000 9999 2000 1 1649
1550 (R) AI502 MN - HI EU -32768 32767 0 0.001 1650
1551 (R) AI502 MN - LO EU -32768 32767 0 0.001 1651
1552 (R) AI502 MN TIM ss 0 5999 0 0.01 1652
1553 (R) AI502 MN TIM mm 0 59 0 1 1653
1554 (R) AI502 MN TIM hh 0 23 0 1 1654
1555 (R) AI502 MN DAY dd 1 31 1 1 1655
1556 (R) AI502 MN DAY mm 1 12 1 1 1656
1557 (R) AI502 MN DAY yy 2000 9999 2000 1 1657
1558 (R) AI503 MX - HI EU -32768 32767 0 0.001 1658
1559 (R) AI503 MX - LO EU -32768 32767 0 0.001 1659
1560 (R) AI503 MX TIM ss 0 5999 0 0.01 1660
1561 (R) AI503 MX TIM mm 0 59 0 1 1661
1562 (R) AI503 MX TIM hh 0 23 0 1 1662
1563 (R) AI503 MX DAY dd 1 31 1 1 1663
1564 (R) AI503 MX DAY mm 1 12 1 1 1664
1565 (R) AI503 MX DAY yy 2000 9999 2000 1 1665
1566 (R) AI503 MN - HI EU -32768 32767 0 0.001 1666
Table E.34 Modbus Register Map
a
(Sheet 29 of 38)
Modbus Register
Address
b
Name/Enums Units Min Max Default
Scale
Fac to r
DeviceNet
Parameter
Numbers
