E.54
SEL-751 Relay Instruction Manual Date Code 20170927
Modbus RTU Communications
Communications Protocol
1567 (R) AI503 MN - LO EU -32768 32767 0 0.001 1667
1568 (R) AI503 MN TIM ss 0 5999 0 0.01 1668
1569 (R) AI503 MN TIM mm 0 59 0 1 1669
1570 (R) AI503 MN TIM hh 0 23 0 1 1670
1571 (R) AI503 MN DAY dd 1 31 1 1 1671
1572 (R) AI503 MN DAY mm 1 12 1 1 1672
1573 (R) AI503 MN DAY yy 2000 9999 2000 1 1673
1574 (R) AI504 MX - HI EU -32768 32767 0 0.001 1674
1575 (R) AI504 MX - LO EU -32768 32767 0 0.001 1675
1576 (R) AI504 MX TIM ss 0 5999 0 0.01 1676
1577 (R) AI504 MX TIM mm 0 59 0 1 1677
1578 (R) AI504 MX TIM hh 0 23 0 1 1678
1579 (R) AI504 MX DAY dd 1 31 1 1 1679
1580 (R) AI504 MX DAY mm 1 12 1 1 1680
1581 (R) AI504 MX DAY yy 2000 9999 2000 1 1681
1582 (R) AI504 MN - HI EU -32768 32767 0 0.001 1682
1583 (R) AI504 MN - LO EU -32768 32767 0 0.001 1683
1584 (R) AI504 MN TIM ss 0 5999 0 0.01 1684
1585 (R) AI504 MN TIM mm 0 59 0 1 1685
1586 (R) AI504 MN TIM hh 0 23 0 1 1686
1587 (R) AI504 MN DAY dd 1 31 1 1 1687
1588 (R) AI504 MN DAY mm 1 12 1 1 1688
1589 (R) AI504 MN DAY yy 2000 9999 2000 1 1689
1590 (R) AI505 MX - HI EU -32768 32767 0 0.001 1690
1591 (R) AI505 MX - LO EU -32768 32767 0 0.001 1691
1592 (R) AI505 MX TIM ss 0 5999 0 0.01 1692
1593 (R) AI505 MX TIM mm 0 59 0 1 1693
1594 (R) AI505 MX TIM hh 0 23 0 1 1694
1595 (R) AI505 MX DAY dd 1 31 1 1 1695
1596 (R) AI505 MX DAY mm 1 12 1 1 1696
1597 (R) AI505 MX DAY yy 2000 9999 2000 1 1697
1598 (R) AI505 MN - HI EU -32768 32767 0 0.001 1698
1599 (R) AI505 MN - LO EU -32768 32767 0 0.001 1699
1600 (R) AI505 MN TIM ss 0 5999 0 0.01 1700
1601 (R) AI505 MN TIM mm 0 59 0 1 1701
1602 (R) AI505 MN TIM hh 0 23 0 1 1702
1603 (R) AI505 MN DAY dd 1 31 1 1 1703
1604 (R) AI505 MN DAY mm 1 12 1 1 1704
1605 (R) AI505 MN DAY yy 2000 9999 2000 1 1705
1606 (R) AI506 MX - HI EU -32768 32767 0 0.001 1706
1607 (R) AI506 MX - LO EU -32768 32767 0 0.001 1707
1608 (R) AI506 MX TIM ss 0 5999 0 0.01 1708
1609 (R) AI506 MX TIM mm 0 59 0 1 1709
1610 (R) AI506 MX TIM hh 0 23 0 1 1710
1611 (R) AI506 MX DAY dd 1 31 1 1 1711
Table E.34 Modbus Register Map
a
(Sheet 30 of 38)
Modbus Register
Address
b
Name/Enums Units Min Max Default
Scale
Fac to r
DeviceNet
Parameter
Numbers
