Schweitzer Engineering Laboratories SEL-751 - Page 769

E.55
Date Code 20170927 Instruction Manual SEL-751 Relay
Modbus RTU Communications
Communications Protocol
1612 (R) AI506 MX DAY mm 1 12 1 1 1712
1613 (R) AI506 MX DAY yy 2000 9999 2000 1 1713
1614 (R) AI506 MN - HI EU -32768 32767 0 0.001 1714
1615 (R) AI506 MN - LO EU -32768 32767 0 0.001 1715
1616 (R) AI506 MN TIM ss 0 5999 0 0.01 1716
1617 (R) AI506 MN TIM mm 0 59 0 1 1717
1618 (R) AI506 MN TIM hh 0 23 0 1 1718
1619 (R) AI506 MN DAY dd 1 31 1 1 1719
1620 (R) AI506 MN DAY mm 1 12 1 1 1720
1621 (R) AI506 MN DAY yy 2000 9999 2000 1 1721
1622 (R) AI507 MX - HI EU -32768 32767 0 0.001 1722
1623 (R) AI507 MX - LO EU -32768 32767 0 0.001 1723
1624 (R) AI507 MX TIM ss 0 5999 0 0.01 1724
1625 (R) AI507 MX TIM mm 0 59 0 1 1725
1626 (R) AI507 MX TIM hh 0 23 0 1 1726
1627 (R) AI507 MX DAY dd 1 31 1 1 1727
1628 (R) AI507 MX DAY mm 1 12 1 1 1728
1629 (R) AI507 MX DAY yy 2000 9999 2000 1 1729
1630 (R) AI507 MN - HI EU -32768 32767 0 0.001 1730
1631 (R) AI507 MN - LO EU -32768 32767 0 0.001 1731
1632 (R) AI507 MN TIM ss 0 5999 0 0.01 1732
1633 (R) AI507 MN TIM mm 0 59 0 1 1733
1634 (R) AI507 MN TIM hh 0 23 0 1 1734
1635 (R) AI507 MN DAY dd 1 31 1 1 1735
1636 (R) AI507 MN DAY mm 1 12 1 1 1736
1637 (R) AI507 MN DAY yy 2000 9999 2000 1 1737
1638 (R) AI508 MX - HI EU -32768 32767 0 0.001 1738
1639 (R) AI508 MX - LO EU -32768 32767 0 0.001 1739
1640 (R) AI508 MX TIM ss 0 5999 0 0.01 1740
1641 (R) AI508 MX TIM mm 0 59 0 1 1741
1642 (R) AI508 MX TIM hh 0 23 0 1 1742
1643 (R) AI508 MX DAY dd 1 31 1 1 1743
1644 (R) AI508 MX DAY mm 1 12 1 1 1744
1645 (R) AI508 MX DAY yy 2000 9999 2000 1 1745
1646 (R) AI508 MN - HI EU -32768 32767 0 0.001 1746
1647 (R) AI508 MN - LO EU -32768 32767 0 0.001 1747
1648 (R) AI508 MN TIM ss 0 5999 0 0.01 1748
1649 (R) AI508 MN TIM mm 0 59 0 1 1749
1650 (R) AI508 MN TIM hh 0 23 0 1 1750
1651 (R) AI508 MN DAY dd 1 31 1 1 1751
1652 (R) AI508 MN DAY mm 1 12 1 1 1752
1653 (R) AI508 MN DAY yy 2000 9999 2000 1 1753
Table E.34 Modbus Register Map
a
(Sheet 31 of 38)
Modbus Register
Address
b
Name/Enums Units Min Max Default
Scale
Fac to r
DeviceNet
Parameter
Numbers
