F.32
SEL-751 Relay Instruction Manual Date Code 20170927
IEC 61850 Communications
Logical Nodes
METMMXU1 A.phsA.instCVal.mag.f IA_MAG Current, A-phase, magnitude
METMMXU1 A.phsB.instCVal.ang.f IB_ANG Current, B-phase, angle
METMMXU1 A.phsB.instCVal.mag.f IB_MAG Current, B-phase, magnitude
METMMXU1 A.phsC.instCVal.ang.f IC_ANG Current, C-phase, angle
METMMXU1 A.phsC.instCVal.mag.f IC_MAG Current, C-phase, magnitude
METMMXU1 A.res.instCVal.ang.f IG_ANG Current, calculated-residual, angle
METMMXU1 A.res.instCVal.mag.f IG_MAG Current, calculated-residual, magnitude
METMMXU1 A.neut.instCVal.ang.f IN_ANG Neutral current, angle
METMMXU1 A.neut.instCVal.mag.f IN_MAG Neutral current, magnitude
METMMXU1 Hz.instMag.f FREQ Frequency
METMMXU1 PF.phsA.instCVal.mag.f PFA Power factor, A-phase, magnitude
METMMXU1 PF.phsB.instCVal.mag.f PFB Power factor, B-phase, magnitude
METMMXU1 PF.phsC.instCVal.mag.f PFC Power factor, C-phase, magnitude
METMMXU1 PhV.phsA.instCVal.ang.f VA_ANG Voltage, A-phase-to-neutral, angle
METMMXU1 PhV.phsA.instCVal.mag.f VA_MAG Voltage, A-phase-to-neutral, magnitude
METMMXU1 PhV.phsB.instCVal.ang.f VB_ANG Voltage, B-phase-to-neutral, angle
METMMXU1 PhV.phsB.instCVal.mag.f VB_MAG Voltage, B-phase-to-neutral, magnitude
METMMXU1 PhV.phsC.instCVal.ang.f VC_ANG Voltage, C-phase-to-neutral, angle
METMMXU1 PhV.phsC.instCVal.mag.f VC_MAG Voltage, C-phase-to-neutral, magnitude
METMMXU1 PhV.res.instCVal.ang.f VG_ANG Zero-sequence voltage, angle
METMMXU1 PhV.res.instCVal.mag.f VG_MAG Zero-sequence voltage, magnitude
METMMXU1 PPV.phsAB.instCVal.ang.f VAB_ANG Voltage, A-to-B-phase, angle
METMMXU1 PPV.phsAB.instCVal.mag.f VAB_MAG Voltage, A-to-B-phase, magnitude
METMMXU1 PPV.phsBC.instCVal.ang.f VBC_ANG Voltage, B-to-C-phase, angle
METMMXU1 PPV.phsBC.instCVal.mag.f VBC_MAG Voltage, B-to-C-phase, magnitude
METMMXU1 PPV.phsCA.instCVal.ang.f VCA_ANG Voltage, C-to-A-phase, angle
METMMXU1 PPV.phsCA.instCVal.mag.f VCA_MAG Voltage, C-to-A-phase, magnitude
METMMXU1 TotPF.instMag.f PF Power factor, three-phase, magnitude
METMMXU1 TotVA.instMag.f S Apparent power, three-phase, magnitude
METMMXU1 TotVAr.instMag.f Q Reactive power, three-phase, magnitude
METMMXU1 TotW.instMag.f P Real power, three-phase, magnitude
METMMXU1 VA.phsA.instCVal.mag.f SA Apparent power, A-phase, magnitude
METMMXU1 VA.phsB.instCVal.mag.f SB Apparent power, B-phase, magnitude
METMMXU1 VA.phsC.instCVal.mag.f SC Apparent power, C-phase, magnitude
Table F.21 Logical Device: MET (Metering) (Sheet 2 of 5)
Logical Node Attribute Data Source Comment
