Date Code 20170927 Instruction Manual SEL-751 Relay
IEC 61850 Communications
Logical Nodes
METMMXU1 VAr.phsA.instCVal.mag.f QA Reactive power, A-phase, magnitude
METMMXU1 VAr.phsB.instCVal.mag.f QB Reactive power, B-phase, magnitude
METMMXU1 VAr.phsC.instCVal.mag.f QC Reactive power, C-phase, magnitude
METMMXU1 W.phsA.instCVal.mag.f PA Real power, A-phase, magnitude
METMMXU1 W.phsB.instCVal.mag.f PB Real power, B-phase, magnitude
METMMXU1 W.phsC.instCVal.mag.f PC Real power, C-phase, magnitude
METMMXU1 VSyn.instCVal.ang.f VS_ANG Synchronizing voltage angle
METMMXU1 VSyn.instCVal.mag.f VS_MAG Synchronizing voltage magnitude
METMMXU1 Fs.instMag.f FREQS Synchronizing frequency
METMSQI1 MaxImbA.instMag.f UBI Current imbalance
METMSQI1 MaxImbV.instMag.f UBV Voltage imbalance
METMSQI1 SeqA.c1.instCVal.ang.f I1_ANG Positive-sequence current, angle
METMSQI1 SeqA.c1.instCVal.mag.f I1_MAG Positive-sequence current, magnitude
METMSQI1 SeqA.c2.instCVal.ang.f I2_ANG Negative-sequence current, angle
METMSQI1 SeqA.c2.instCVal.mag.f 3I2 Negative-sequence current, magnitude
METMSQI1 SeqA.c3.instCVal.ang.f IG_ANG Current, calculated-residual, angle
METMSQI1 SeqA.c3.instCVal.mag.f IG_MAG Current, calculated-residual, magnitude
METMSQI1 SeqV.c1.instCVal.ang.f V1_ANG Positive-sequence voltage, angle
METMSQI1 SeqV.c1.instCVal.mag.f V1_MAG Positive-sequence voltage, magnitude
METMSQI1 SeqV.c2.instCVal.ang.f V2_ANG Negative-sequence voltage, angle
METMSQI1 SeqV.c2.instCVal.mag.f 3V2 Negative-sequence voltage, magnitude
METMSQI1 SeqV.c3.instCVal.ang.f VG_ANG Zero-sequence voltage, angle
METMSQI1 SeqV.c3.instCVal.mag.f VG_MAG Zero-sequence voltage, magnitude
METMSTA1 AvAmps.instMag.f IAV Current, average current, magnitude
METMSTA1 AvVolts.instMag.f VAVE Average voltage, magnitude
METMSTA1 MaxA.phsA.instCVal.mag.f IAMX Current, A-phase, maximum magnitude
METMSTA1 MaxA.phsB.instCVal.mag.f IBMX Current, B-phase, maximum magnitude
METMSTA1 MaxA.phsC.instCVal.mag.f ICMX Current, C-phase, maximum magnitude
METMSTA1 MaxA.res.instCVal.mag.f IGMX Current, residual, maximum magnitude
METMSTA1 MaxA.neut.instCVal.mag.f INMX Current, neutral, maximum magnitude
METMSTA1 MaxP2PV.phsAB.instCVal.mag.f VABMX Voltage, A-to-B-phase, maximum magnitude
METMSTA1 MaxP2PV.phsBC.instCVal.mag.f VBCMX Voltage, B-to-C-phase, maximum magnitude
METMSTA1 MaxP2PV.phsCA.instCVal.mag.f VCAMX Voltage, C-to-A-phase, maximum magnitude
METMSTA1 MaxPhV.phsA.instCVal.mag.f VAMX Voltage, A-phase-to-neutral, maximum magnitude
Table F.21 Logical Device: MET (Metering) (Sheet 3 of 5)
Logical Node Attribute Data Source Comment
