Schweitzer Engineering Laboratories SEL-751 - Page 810

F.34
SEL-751 Relay Instruction Manual Date Code 20170927
IEC 61850 Communications
Logical Nodes
METMSTA1 MaxPhV.phsB.instCVal.mag.f VBMX Voltage, B-phase-to-neutral, maximum magnitude
METMSTA1 MaxPhV.phsC.instCVal.mag.f VCMX Voltage, C-phase-to-neutral, maximum magnitude
METMSTA1 MaxVs.instMag.f VSMX Synchronizing voltage, maximum magnitude
METMSTA1 MaxVA.instMag.f KVA3PMX Apparent power, three-phase, maximum magnitude
METMSTA1 MaxVAr.instMag.f KVAR3PMX Reactive power, three-phase, maximum magnitude
METMSTA1 MaxW.instMag.f KW3PMX Real power, three-phase, maximum magnitude
METMSTA1 MinA.phsA.instCVal.mag.f IAMN Current, A-phase, minimum magnitude
METMSTA1 MinA.phsB.instCVal.mag.f IBMN Current, B-phase, minimum magnitude
METMSTA1 MinA.phsC.instCVal.mag.f ICMN Current, C-phase, minimum magnitude
METMSTA1 MinA.res.instCVal.mag.f IGMN Current, residual, minimum magnitude
METMSTA1 MinA.neut.instCVal.mag.f INMN Current, neutral, minimum magnitude
METMSTA1 MinP2PV.phsAB.instCVal.mag.f VABMN Voltage, A-to-B-phase, minimum magnitude
METMSTA1 MinP2PV.phsBC.instCVal.mag.f VBCMN Voltage, B-to-C-phase, minimum magnitude
METMSTA1 MinP2PV.phsCA.instCVal.mag.f VCAMN Voltage, C-to-A-phase, minimum magnitude
METMSTA1 MinPhV.phsA.instCVal.mag.f VAMN Voltage, A-phase-to-neutral, minimum magnitude
METMSTA1 MinPhV.phsB.instCVal.mag.f VBMN Voltage, B-phase-to-neutral, minimum magnitude
METMSTA1 MinPhV.phsC.instCVal.mag.f VCMN Voltage, C-phase-to-neutral, minimum magnitude
METMSTA1 MinVs.instMag.f VSMN Synchronizing voltage, minimum magnitude
METMSTA1 MinVA.instMag.f KVA3PMN Apparent power, three-phase, minimum magnitude
METMSTA1 MinVAr.instMag.f KVAR3PMN Reactive power, three-phase, minimum magnitude
METMSTA1 MinW.instMag.f KW3PMN Real power, three-phase, minimum magnitude
RMSMMXU2 A.phsA.instCVal.mag.f IARMS RMS current, A-phase, magnitude
RMSMMXU2 A.phsB.instCVal.mag.f IBRMS RMS current, B-phase, magnitude
RMSMMXU2 A.phsC.instCVal.mag.f ICRMS RMS current, C-phase, magnitude
RMSMMXU2 A.neut.instCVal.mag.f INRMS RMS current, neutral, magnitude
RMSMMXU2 PhV.phsA.instCVal.mag.f VARMS RMS voltage, A-phase, magnitude
RMSMMXU2 PhV.phsB.instCVal.mag.f VBRMS RMS voltage, B-phase, magnitude
RMSMMXU2 PhV.phsC.instCVal.mag.f VCRMS RMS voltage, C-phase, magnitude
RMSMMXU2 PPV.phsAB.instCVal.mag.f VABRMS RMS voltage, AB-phase-to-phase, magnitude
RMSMMXU2 PPV.phsBC.instCVal.mag.f VBCRMS RMS voltage, BC-phase-to-phase, magnitude
RMSMMXU2 PPV.phsCA.instCVal.mag.f VCARMS RMS voltage, CA-phase-to-phase, magnitude
RMSMMXU2 VSyn.instCVal.mag.f VSRMS Synchronizing voltage, RMS magnitude
THERMMTHR1 MaxAmbTmp.instMag.f RTDAMB
c
Ambient RTD temperature
THERMMTHR1 MaxBrgTmp.instMag.f RTDBRGMX
c
Maximum bearing RTD temperature
Table F.21 Logical Device: MET (Metering) (Sheet 4 of 5)
Logical Node Attribute Data Source Comment
