L.5
Date Code 20170927 Instruction Manual SEL-751 Relay
Analog Quantities
Maximum/Minimum Metering
Note8: For each of the maximum or minimum analog quantities, the corresponding time stamp is also reported in Modbus. In
addition, the time when Max/Min data was last reset is also reported in Modbus (the actual labels used in the Modbus
Map are not MM_LRDH, MM_LRDM, MM_LRDL).
Note9: EU is Engineering Units.
MM_LRDH
8
Max/min last reset date/time high word x
7
MM_LRDM
8
Max/min last reset date/time middle word x
7
MM_LRDL
8
Max/min last reset date/time low word x
7
IAMX A-phase maximum current A pri xxxx x x
IBMX B-phase maximum current A pri xxxx x x
ICMX C-phase maximum current A pri xxxx x x
INMX Neutral maximum current A pri xxxx x x
IGMX Calculated residual maximum current A pri xxxx x x
IAMN A-phase minimum current A pri xxxx x x
IBMN B-phase minimum current A pri xxxx x x
ICMN C-phase minimum current A pri xxxx x x
INMN Neutral minimum current A pri xxxx x x
IGMN Calculated residual minimum current A pri xxxx x x
VABMX A-to-B-phase maximum voltage V pri xxxx x x
VBCMX B-to-C-phase maximum voltage V pri xxxx x x
VCAMX C-to-A-phase maximum voltage V pri xxxx x x
VAMX A-phase maximum voltage V pri xxxx x x
VBMX B-phase, maximum voltage V pri xxxx x x
VCMX C-phase maximum voltage V pri xxxx x x
VSMX Vsync maximum voltage V pri x x x
VABMN A-to-B-phase minimum voltage V pri xxxx x x
VBCMN B-to-C-phase minimum voltage V pri xxxx x x
VCAMN C-to-A-phase minimum voltage V pri xxxx x x
VAMN A-phase minimum voltage V pri xxxx x x
VBMN B-phase minimum voltage V pri xxxx x x
VCMN C-phase minimum voltage V pri xxxx x x
VSMN Vsync minimum voltage V pri x x x x x
KVA3PMX Three-phase maximum apparent power kVA pri xxxx x x
KW3PMX Three-phase maximum real power kW pri xxxx x x
KVAR3PMX Three-phase maximum reactive power kVAR pri xxxx x x
KVA3PMN Three-phase minimum apparent power kVA pri xxxx x x
KW3PMN Three-phase minimum real power kW pri xxxx x x
KVAR3PMN Three-phase minimum reactive power kVAR pri xxxx x x
FREQMX Maximum frequency Hz xxxx x x
FREQMN Minimum frequency Hz xxxx x x
RTD1MX to RTD12MXRTD1 maximum to RTD12 maximum °C xxxx x x
RTD1MN to RTD12MNRTD1 minimum to RTD12 minimum °C xxxx x x
AI301MX to AI308MX Analog transducer input 301–308 maximum EU
9
xxxx x x
AI301MN to AI308MN Analog transducer input 301–308 minimum EU
9
xxxx x x
AI401MX to AI408MX Analog transducer input 401–408 maximum EU
9
xxxx x x
Table L.1 Analog Quantities (Sheet 5 of 8)
Name Description Units
Display Points
SELOGIC
Load Profile
DNP3/Fast Message Read/
IEC 60870-5-103
Modbus
Fast Meter
IEC 61850
