Xerox DocuColor 1632 Service Manual

6/02
2-235
DC1632/2240
12-902
Status Indicator RAPs
Prelaunch Training/Review
12-902 Power On H Transport Exit Sensor
The H Transport Exit Sensor detected a paper at power on, when all the INTERLOCK were
closed, or at initialization.
Procedure
Check the following:
ï The Actuator for return failure
ï Enter dC330 [012-104] and press Start. Check only the signal wire of the sensor.
ï Check that the power voltage at the customer site does not drop.
Figure 1 Component Location
Figure 2 H Transport Sensor CD
Figure 3 Finisher PWB
Exit
Sensor
