Xerox DocuColor 1632 Service Manual

6/02
6-33
DC1632/2240
General Procedures and Information
Prelaunch Training/Review
752-xxx Procon NVM List
751-178 P/R Life End of Life (Limiter) 280 0~500 End of Life value of Drum Cartridge (All engine common) (1 Count=1kCy)
751-200 #Y_BCR DC corrected VH value 620 0~1023 VH Output Value of #Y Engine after Correction (All Speed common) (1 Count=-1.173V)
751-201 #M_BCR DC corrected VH value 620 0~1023 VH Output Value of #M Engine after Correction (All Speed common) (1 Count=-1.173V)
751-202 #C_BCR DC corrected VH value 620 0~1023 VH Output Value of #C Engine after Correction (All Speed common) (1 Count=-1.173V)
751-203 #K_BCR DC corrected VH value 620 0~1023 VH Output Value of #K Engine after Correction (All Speed common) (1 Count=-1.173V)
Table 11 Chain 751
Chain-Link Name Default Range Description
Table 12 Chain 752
Chain-Link Name Default Range Description
752-027 Vdark Average 0 0~1023 ADC average detected value at expansion LED OFF.
752-028 Vref Average 0 0~1023 ADC average detected value of reference board reflection at expansiON. ON.
752-029 Vcln Average 0 0~1023 ADC average detected value of belt reflection at expansiON. ON.
752-030 Diffusion Vcln Average 0 0~1023 ADC average detected value of Belt reflection Light at diffusiON. ON.
752-031 Vpatch Average [Y] [CinA] 0 0~1023 ADC average detected value of CinA (low Cin) Patch.
752-032 Vpatch Average [M] [CinA] 0 0~1023 ADC average detected value of CinA (low Cin) Patch.
752-033 Vpatch Average [C] [CinA] 0 0~1023 ADC average detected value of CinA (low Cin) Patch.
752-034 Vpatch Average [K] [CinA] 0 0~1023 ADC average detected value of CinA (low Cin) Patch.
752-035 Vpatch Average [Y] [CinB] 0 0~1023 ADC average detected value of CinB (high Cin) Patch.
752-036 Vpatch Average [M] [CinB] 0 0~1023 ADC average detected value of CinB (high Cin) Patch.
752-037 Vpatch Average [C] [CinB] 0 0~1023 ADC average detected value of CinB (high Cin) Patch.
752-038 Vpatch Average [K] [CinB] 0 0~1023 ADC average detected value of CinB (high Cin) Patch.
752-050 Fail ADC Sensor 0 0~1 ADC Sensor Fail
752-051 Fail ADC Shutter 0 0~1 ADC Shutter Fail
752-052 Fail ADC Patch [Y] 0 0~1 ADC Patch Fail
752-053 Fail ADC Patch [M] 0 0~1 ADC Patch Fail
752-054 Fail ADC Patch [C] 0 0~1 ADC Patch Fail
752-055 Fail ADC Patch [K] 0 0~1 ADC Patch Fail
752-056 Diffusion Correction Factor 350 0~1023 Diffusion Output Standardization factor
752-057 RADC Target [Y] 415 0~1023 RADC Control Density Target Value
752-058 RADC Target [M] 360 0~1023 RADC Control Density Target Value
752-059 RADC Target [C] 355 0~1023 RADC Control Density Target Value
752-060 RADC Target [K] 310 0~1023 RADC Control Density Target Value
752-061 RADC Average [Y] 400 0~1023 RADC shift average value
752-062 RADC Average [M] 370 0~1023 RADC shift average value
752-063 RADC Average [C] 338 0~1023 RADC shift average value
752-064 RADC Average [K] 380 0~1023 RADC shift average value
752-069 ATC Correction Factor [Y] 1000 0~4095 ATC Sensor Sensitivity Correction Factor
752-070 ATC Correction Factor [Y] 1000 0~4095 ATC Sensor Sensitivity Correction Factor
752-071 ATC Correction Factor [Y] 1000 0~4095 ATC Sensor Sensitivity Correction Factor
752-072 ATC Correction Factor [Y] 1000 0~4095 ATC Sensor Sensitivity Correction Factor
