Xerox DocuColor 1632 Service Manual

6/02
6-34
DC1632/2240
Prelaunch Training/Review
General Procedures and Information
752-073 ATC Correction Offset [Y] 10000 8976~11023 ATC Sensor Sensitivity Correction Offset
752-074 ATC Correction Offset [M] 10000 8976~11023 ATC Sensor Sensitivity Correction Offset
752-075 ATC Correction Offset [C] 10000 8976~11023 ATC Sensor Sensitivity Correction Offset
752-076 ATC Correction Offset [K] 10000 8976~11023 ATC Sensor Sensitivity Correction Offset
752-081 ATC Average [Y] 0 0~1023 ATC Average detected value after sensor sensitivity correction
752-082 ATC Average [M] 0 0~1023 ATC Average detected value after sensor sensitivity correction
752-083 ATC Average [C] 0 0~1023 ATC Average detected value after sensor sensitivity correction
752-084 ATC Average [K] 0 0~1023 ATC Average detected value after sensor sensitivity correction
752-089 ATC Fluctuation [Y] 0 0~1023 ATC Fluctuation Range detected value after sensor sensitivity correction
752-090 ATC Fluctuation [M] 0 0~1023 ATC Fluctuation Range detected value after sensor sensitivity correction
752-091 ATC Fluctuation [C] 0 0~1023 ATC Fluctuation Range detected value after sensor sensitivity correction
752-092 ATC Fluctuation [K] 0 0~1023 ATC Fluctuation Range detected value after sensor sensitivity correction
752-109 Number of Continuous ATC Fails [Y] 0 0~255 No. of Continuous ATC Fails
752-110 Number of Continuous ATC Fails [M] 0 0~255 No. of Continuous ATC Fails
752-111 Number of Continuous ATC Fails [C] 0 0~255 No. of Continuous ATC Fails
752-112 Number of Continuous ATC Fails [K] 0 0~255 No. of Continuous ATC Fails
752-114 Warn ATC Max & Min [Y] 0 0~2 ATC Upper and Lower Limits Warning (0 = Normal, 1 = ATC Output low HiTC, 2 = ATC Output high LowTC)
752-115 Warn ATC Max & Min [M] 0 0~2 ATC Upper and Lower Limits Warning (0 = Normal, 1 = ATC Output low HiTC, 2 = ATC Output high LowTC)
752-116 Warn ATC Max & Min [C] 0 0~2 ATC Upper and Lower Limits Warning (0 = Normal, 1 = ATC Output low HiTC, 2 = ATC Output high LowTC)
752-117 Warn ATC Max & Min [K] 0 0~2 ATC Upper and Lower Limits Warning (0 = Normal, 1 = ATC Output low HiTC, 2 = ATC Output high LowTC)
752-118 Warn ATC Fluctuation Max & Min [Y] 0 0~2 ATC Fluctuation Range Lower Limit Warning (0 = Normal, 1 = To little fluctuation)
752-119 Warn ATC Fluctuation Max & Min [M] 0 0~2 ATC Fluctuation Range Lower Limit Warning (0 = Normal, 1 = To little fluctuation)
752-120 Warn ATC Fluctuation Max & Min [C] 0 0~2 ATC Fluctuation Range Lower Limit Warning (0 = Normal, 1 = To little fluctuation)
752-121 Warn ATC Fluctuation Max & Min [K] 0 0~2 ATC Fluctuation Range Lower Limit Warning (0 = Normal, 1 = To little fluctuation)
752-122 Fail ATC Patch [Y] 0 0~1 ATC Sensor Fail
752-123 Fail ATC Sensor [M] 0 0~1 ATC Sensor Fail
752-124 Fail ATC Sensor [C] 0 0~1 ATC Sensor Fail
752-125 Fail ATC Sensor [K] 0 0~1 ATC Sensor Fail
752-130 Set ATC Control Nominal Value [0] [Y] 628 0~1023 ATC Control Nominal Value before environment/deterioration correction as center setup
752-131 Set ATC Control Nominal Value [0] [M] 628 0~1023 ATC Control Nominal Value before environment/deterioration correction as center setup
752-132 Set ATC Control Nominal Value [0] [C] 628 0~1023 ATC Control Nominal Value before environment/deterioration correction as center setup
752-133 Set ATC Control Nominal Value [0] [K] 643 0~1023 ATC Control Nominal Value before environment/deterioration correction as center setup
752-134 Set ATC Control Nominal Value [1] [Y] 668 0~1023 ATC Control Nominal Value before environment/deterioration correction as center setup
752-135 Set ATC Control Nominal Value [1] [M] 668 0~1023 ATC Control Nominal Value before environment/deterioration correction as center setup
752-136 Set ATC Control Nominal Value [1] [C] 668 0~1023 ATC Control Nominal Value before environment/deterioration correction as center setup
752-137 Set ATC Control Nominal Value [1] [K] 683 0~1023 [ATC Control Nominal Value before environment/deterioration correction as center setup
752-138 Set ATC Control Nominal Value [2] [K] 603 0~1023 ATC Control Nominal Value before environment/deterioration correction as center setup
752-156 ATC Control Nominal Value [Y] 500 0~1023 [Set ATC Control Nominal Value]+[ATC Environment Correction Value]+[ATC Deterioration Correction
Value]+[ATC Nominal Value OFFSET]
752-157 ATC Control Nominal Value [M] 500 0~1023 [Set ATC Control Nominal Value]+[ATC Environment Correction Value]+[ATC Deterioration Correction
Value]+[ATC Nominal Value OFFSET]
Table 12 Chain 752
Chain-Link Name Default Range Description
