General Procedures and Information
Prelaunch Training/Review
752-158 ATC Control Nominal Value [C] 500 0~1023 [Set ATC Control Nominal Value]+[ATC Environment Correction Value]+[ATC Deterioration Correction
Value]+[ATC Nominal Value OFFSET]
752-159 ATC Control Nominal Value [K] 500 0~1023 [Set ATC Control Nominal Value]+[ATC Environment Correction Value]+[ATC Deterioration Correction
Value]+[ATC Nominal Value OFFSET]
752-162 Temp Average 100 80~200 Temperature average value after converting the temperature sensor output to temperature (80 = -20 Degree
Celsius, 100 = 0 Degree Celsius, 200 = 100 Degree Celsius)
752-163 Humidity Average 0 0~100 Humidity average value after converting the humidity sensor output to humidity
752-176 Fail Environment SNR TEMP 0 0~1 [Detection relation (Temperature/Humidity)] Temperature Sensor Fail (Fixed as [Standard Temperature])
752-177 Fail Environment SNR Humidity 0 0~1 [Detection relation (Temperature/Humidity)] Temperature Sensor Fail (Fixed as [Standard Temperature])
752-324 SW_DispMode 0 0~2 Dispense method changing SW (0=ATC+ICDC, 1=ICDC, 2=Timer Disp)
752-357 Timer Disp time [Y] 5 0~250 Timer Disp Setup Time
752-358 Timer Disp time [M] 5 0~250 Timer Disp Setup Time
752-359 Timer Disp time [C] 5 0~250 Timer Disp Setup Time
752-360 Timer Disp time [K] 5 0~250 Timer Disp Setup Time
752-369 SW Potential Control ON/OFF 0 0~1 0 = Controls LD Light Quantity 1 = Fixed LD Light Quantity
752-371 LD Light qty. when Potential Control is
OFF [Y]
300 0~1023 LD Light Quantity Value when Potential Control is OFF.
752-372 LD Light qty when Potential Control is
OFF [M]
300 0~1023 LD Light Quantity Value when Potential Control is OFF.
752-373 LD Light qty when Potential Control is
OFF [C]
300 0~1023 LD Light Quantity Value when Potential Control is OFF.
752-374 LD Light qty when Potential Control is
OFF [K]
300 0~1023 LD Light Quantity Value when Potential Control is OFF.
752-375 Ideal LD light qty [Y] 450 0~1023 LD Light Quantity Ideal Value Calculated from Delta LD Light Quantity.
752-376 Ideal LD light qty [M] 450 0~1023 LD Light Quantity Ideal Value Calculated from Delta LD Light Quantity.
752-377 Ideal LD light qty [C] 450 0~1023 LD Light Quantity Ideal Value Calculated from Delta LD Light Quantity.
752-378 Ideal LD light qty [K] 400 0~1023 LD Light Quantity Ideal Value Calculated from Delta LD Light Quantity.
752-394 Change in Lim_d_LD Light qty on Job-
start
40 0~1023 Limit of Delta LD Light Quantity Feedback at Job Start.
752-395 Change in Lim_d_LD Light qty on Job &
Jobend
20 0~1023 Limit of Delta LD Light Quantity Feedback at Job End/during Job.
752-396 Change in Lim_d_LD Light qty on Ton-
erRecovery
200 0~1023 Limit of Delta LD Light Quantity Feedback at recovery.
752-397 Change in Lim_d_LD Light qty on Job-
start (CL)
40 0~1023 Limit of Delta LD Light Quantity Feedback at Job Start (YMC Color differences considered)
752-398 Change in Lim_d_LD Light qty on Job &
Jobend (CL)
20 0~1023 Limit of Delta LD Light Quantity Feedback at Job End/during Job (YMC Color differences considered)
752-439 Warn LD light amount Setting [Y] 0 0~1 Warning when the LD Light Quantity reached Upper or Lower Limit.
752-440 Warn LD light amount Setting [M] 0 0~1 Warning when the LD Light Quantity reached Upper or Lower Limit.
752-441 Warn LD light amount Setting [C] 0 0~1 Warning when the LD Light Quantity reached Upper or Lower Limit.
752-442 Warn LD light amount Setting [K] 0 0~1 Warning when the LD Light Quantity reached Upper or Lower Limit.
752-453 VBias [Y] 887 0~1023 DC VBias value
752-454 VBias [M] 887 0~1023 DC VBias value
Table 12 Chain 752
Chain-Link Name Default Range Description
