Xerox DocuColor 1632 Service Manual

6/02
7-4
DC1632/2240
Plug/Jack Locations
Prelaunch Training/Review
Wiring Data
230 Figure 9 9 Toner Dispense Motor, Main Switch
231 Figure 5 5 Registration Transport Assembly
232 Figure 17 9 Developer Motor, Tray 1 Size Switch
233 Figure 1 2 Xerographic
234 Figure 17 1 Developer Motor, Tray 1 Size Switch
235 Figure 17 2 Developer Motor, Tray 1 Size Switch
237 Figure 11 3 IBT Belt Assembly
240 Figure 5 2 Registration Transport Assembly
251 Figure 3 6 Inverter Transport Assembly
255 Figure 2 4 MOB Sensor Assembly
260 Figure 6 5 Fuser Assembly
261 Figure 6 6 Fuser Assembly
262 Figure 6 3 Fuser Assembly
263 Figure 6 4 Fuser Assembly
264 Figure 6 9 Fuser Assembly
265 Figure 8 2 TRAY 5
288 Figure 9 18 Toner Dispense Motor, Main Switch
300 Figure 14 5 ESS assembly
310 Figure 14 18 ESS assembly
311 Figure 14 6 ESS assembly
J332 Figure 14 1 ESS assembly
333 Figure 14 3 ESS assembly
J335 Figure 14 19 ESS assembly
336 Figure 14 12 ESS assembly
337 Figure 14 8 ESS assembly
338 Figure 14 20 ESS assembly
J340 Figure 14 15 ESS assembly
J341 Figure 14 16 ESS assembly
J342 Figure 14 17 ESS assembly
J343 Figure 14 18 ESS assembly
344 Figure 14 14 ESS assembly
P347 Figure 14 11 ESS assembly
400 Figure 15 8 MCU-MF PWB
401 Figure 15 11 MCU-MF PWB
402 Figure 15 12 MCU-MF PWB
403 Figure 15 2 MCU-MF PWB
404 Figure 15 4 MCU-MF PWB
405 Figure 15 5 MCU-MF PWB
406 Figure 15 6 MCU-MF PWB
Table 1 Plug / Jack Location List
Plug /
Jack
Number
Figure
Number
Item
Number Figure Title
407 Figure 15 3 MCU-MF PWB
J410 Figure 15 10 MCU-MF PWB
P410 Figure 16 4 I/F PWB, MAIN Motor, LVPS T2
J460 Figure 14 7 ESS assembly
P460 Figure 15 1 MCU-MF PWB
J496 Figure 15 9 MCU-MF PWB
498 Figure 15 7 MCU-MF PWB
501 Figure 12 19 HVPS T5, T7, +24V LVPS
502 Figure 12 6 HVPS T5, T7, +24V LVPS
505 Figure 12 7 HVPS T5, T7, +24V LVPS
510 Figure 16 23 I/F PWB, MAIN Motor, LVPS T2
510B Figure 16 18 I/F PWB, MAIN Motor, LVPS T2
511 Figure 16 15 I/F PWB, MAIN Motor, LVPS T2
514 Figure 10 3 ROS Assembly
515 Figure 10 2 ROS Assembly
516 Figure 10 7 ROS Assembly
517 Figure 10 8 ROS Assembly
518 Figure 10 9 ROS Assembly
526 Figure 10 5 ROS Assembly
527 Figure 10 1 ROS Assembly
528 Figure 10 6 ROS Assembly
529 Figure 10 4 ROS Assembly
530 Figure 16 13 I/F PWB, MAIN Motor, LVPS T2
531 Figure 16 7 I/F PWB, MAIN Motor, LVPS T2
532 Figure 16 14 I/F PWB, MAIN Motor, LVPS T2
533 Figure 16 1 I/F PWB, MAIN Motor, LVPS T2
534 Figure 16 9 I/F PWB, MAIN Motor, LVPS T2
535 Figure 16 20 I/F PWB, MAIN Motor, LVPS T2
536 Figure 16 8 I/F PWB, MAIN Motor, LVPS T2
538 Figure 4 1 Duplex Transport Assembly
539 Figure 4 3 Duplex Transport Assembly
540 Figure 4 4 Duplex Transport Assembly
541 Figure 23 14 TT Module (rear)
546 Figure 23 1 TT Module (rear)
547 Figure 23 4 TT Module (rear)
548 Figure 23 15 TT Module (rear)
549 Figure 23 13 TT Module (rear)
550 Figure 16 3 I/F PWB, MAIN Motor, LVPS T2
550 Figure 26 5 DADF (2 of 2)
Table 1 Plug / Jack Location List
Plug /
Jack
Number
Figure
Number
Item
Number Figure Title
