Plug/Jack Locations
Wiring Data
Prelaunch Training/Review
551 Figure 16 25 I/F PWB, MAIN Motor, LVPS T2
551 Figure 26 4 DADF (2 of 2)
552 Figure 16 26 I/F PWB, MAIN Motor, LVPS T2
552 Figure 23 6 TT Module (rear)
553 Figure 16 17 I/F PWB, MAIN Motor, LVPS T2
553 Figure 23 10 TT Module (rear)
554 Figure 23 11 TT Module (rear)
555 Figure 23 5 TT Module (rear)
557 Figure 23 2 TT Module (rear)
561 Figure 23 12 TT Module (rear)
564 Figure 23 3 TT Module (rear)
568 Figure 16 2 I/F PWB, MAIN Motor, LVPS T2
569 Figure 16 27 I/F PWB, MAIN Motor, LVPS T2
570 Figure 12 4 HVPS T5, T7, +24V LVPS
571 Figure 12 17 HVPS T5, T7, +24V LVPS
572 Figure 12 3 HVPS T5, T7, +24V LVPS
573 Figure 12 1 HVPS T5, T7, +24V LVPS
574 Figure 12 18 HVPS T5, T7, +24V LVPS
575 Figure 16 12 I/F PWB, MAIN Motor, LVPS T2
576 Figure 16 11 I/F PWB, MAIN Motor, LVPS T2
580 Figure 12 14 HVPS T5, T7, +24V LVPS
580 Figure 25 8 DADF (1 of 2)
581 Figure 12 2 HVPS T5, T7, +24V LVPS
581 Figure 25 9 DADF (1 of 2)
582 Figure 25 6 DADF (1 of 2)
583 Figure 25 5 DADF (1 of 2)
585 Figure 25 4 DADF (1 of 2)
586 Figure 25 11 DADF (1 of 2)
587 Figure 25 1 DADF (1 of 2)
588 Figure 26 6 DADF (2 of 2)
589 Figure 26 2 DADF (2 of 2)
590 Figure 18 5 AC Drive PWB, Noise Filter PWB, Delay
PWB
590 Figure 26 7 DADF (2 of 2)
591 Figure 25 2 DADF (1 of 2)
592 Figure 18 6 AC Drive PWB, Noise Filter PWB, Delay
PWB
592 Figure 26 1 DADF (2 of 2)
Table 1 Plug / Jack Location List
Plug /
Jack
Number
Figure
Number
Item
Number Figure Title
593 Figure 18 14 AC Drive PWB, Noise Filter PWB, Delay
PWB
594 Figure 26 9 DADF (2 of 2)
595 Figure 26 10 DADF (2 of 2)
596 Figure 26 13 DADF (2 of 2)
597 Figure 26 8 DADF (2 of 2)
598 Figure 26 11 DADF (2 of 2)
599 Figure 26 3 DADF (2 of 2)
J600 Figure 5 1 Registration Transport Assembly
P600 Figure 6 10 Fuser Assembly
600 Figure 26 12 DADF (2 of 2)
602 Figure 1 24 Xerographic
605 Figure 11 1 IBT Belt Assembly
608 Figure 1 25 Xerographic
J610 Figure 8 1 MSI Unit
P610 Figure 17 3 Developer Motor, Tray 1 Size Switch
611 Figure 7 5 Exit Transport Assembly
J612 Figure 3 9 Inverter Transport Assembly
P612 Figure 17 3 Developer Motor, Tray 1 Size Switch
J613 Figure 3 10 Inverter Transport Assembly
P613 Figure 17 5 Developer Motor, Tray 1 Size Switch
614 Figure 1 18 Xerographic
617 Figure 19 6 Left Lower Assembly, Tray 1 Feeder
619 Figure 1 1 Xerographic
620 Figure 5 6 Registration Transport Assembly
622 Figure 1 22 Xerographic
623 Figure 19 5 Left Lower Assembly, Tray 1 Feeder
624 Figure 1 21 Xerographic
P626 Figure 3 13 Inverter Transport Assembly
J626 Figure 4 2 Duplex Transport Assembly
631 Figure 1 23 Xerographic
J633 Figure 3 3 Inverter Transport Assembly
P633 Figure 3 7 Inverter Transport Assembly
639 Figure 16 5 I/F PWB, MAIN Motor, LVPS T2
J640 Figure 3 11 Inverter Transport Assembly
P640 Figure 17 6 Developer Motor, Tray 1 Size Switch
641 Figure 16 6 I/F PWB, MAIN Motor, LVPS T2
646 Figure 17 8 Developer Motor, Tray 1 Size Switch
668 Figure 12 15 HVPS T5, T7, +24V LVPS
Table 1 Plug / Jack Location List
Plug /
Jack
Number
Figure
Number
Item
Number Figure Title
To Next Page
