Xerox DocuColor 1632 Service Manual

6/02
7-6
DC1632/2240
Plug/Jack Locations
Prelaunch Training/Review
Wiring Data
669 Figure 12 16 HVPS T5, T7, +24V LVPS
670 Figure 20 9 TT Module (Tray 2,3 feeder)
672 Figure 20 7 TT Module (Tray 2,3 feeder)
674 Figure 23 9 TT Module (rear)
700 Figure 28 5 IIT (rear)
702 Figure 28 3 IIT (rear)
705 Figure 28 4 IIT (rear)
J711 Figure 27 8 IIT (front)
P711 Figure 24 10 Control Panel
J712 Figure 27 7 IIT (front)
P712 Figure 24 9 Control Panel
713 Figure 24 5 Control Panel
714 Figure 24 4 Control Panel
715 Figure 24 11 Control Panel
720 Figure 27 3 IIT (front)
721 Figure 27 9 IIT (front)
722 Figure 27 5 IIT (front)
724 Figure 27 2 IIT (front)
725 Figure 27 10 IIT (front)
726 Figure 27 1 IIT (front)
727 Figure 28 9 IIT (rear)
734 Figure 28 7 IIT (rear)
735 Figure 28 6 IIT (rear)
736 Figure 28 8 IIT (rear)
737 Figure 27 4 IIT (front)
738 Figure 28 10 IIT (rear)
739 Figure 28 2 IIT (rear)
741 Figure 27 6 IIT (front)
742 Figure 27 12 IIT (front)
746 Figure 27 11 IIT (front)
747 Figure 27 4 IIT (front)
J750 Figure 28 1 IIT (Rear)
P750 Figure 25 10 DADF (1 0f 2)
765 Figure 25 7 DADF (1 0f 2)
769 Figure 25 3 DADF (1 0f 2)
J800 Figure 31 8 Finisher (rear) (1 0f 2)
P800 Figure 16 21 I/F PWB, MAIN Motor, LVPS T2
801 Figure 12 5 HVPS T5, T7, +24V LVPS
814 Figure 20 5 TT Module (Tray 2,3 feeder)
Table 1 Plug / Jack Location List
Plug /
Jack
Number
Figure
Number
Item
Number Figure Title
815 Figure 20 4 TT Module (Tray 2,3 feeder)
816 Figure 22 5 TT Module (Tray 2,3,4, Paper Size
Switch)
818 Figure 20 5 TT Module (Tray 2,3 feeder)
819 Figure 20 4 TT Module (Tray 2,3 feeder)
820 Figure 22 3 TT Module (Tray 2,3,4, Paper Size
Switch)
821 Figure 20 6 TT Module (Tray 2,3 feeder)
822 Figure 21 1 TT Module (Tray 2,3 feeder)
823 Figure 21 2 TT Module (Tray 2,3 feeder)
824 Figure 22 3 TT Module (Tray 2,3,4, Paper Size
Switch)
825 Figure 21 3 TT Module (Tray 2,3 feeder)
826 Figure 23 7 TT Module (rear)
827 Figure 20 3 TT Module (Tray 2,3 feeder)
828 Figure 20 3 TT Module (Tray 2,3 feeder)
829 Figure 21 4 TT Module (Tray 2,3 feeder)
841 Figure 20 8 TT Module (Tray 2,3 feeder)
842 Figure 23 8 TT Module (rear)
843 Figure 32 9 Finisher PWB
844 Figure 32 8 Finisher PWB
845 Figure 32 5 Finisher PWB
846 Figure 32 6 Finisher PWB
847 Figure 32 7 Finisher PWB
848 Figure 32 3 Finisher PWB
849 Figure 32 4 Finisher PWB
850 Figure 32 12 Finisher PWB
851 Figure 32 10 Finisher PWB
852 Figure 32 11 Finisher PWB
853 Figure 29 4 H-Transport Assembly
854 Figure 29 2 H-Transport Assembly
855 Figure 29 1 H-Transport Assembly
856 Figure 29 8 H-Transport Assembly
858 Figure 29 5 H-Transport Assembly
859 Figure 29 6 H-Transport Assembly
860 Figure 29 3 H-Transport Assembly
861 Figure 29 7 H-Transport Assembly
862 Figure 30 7 Tamper Unit, Staple Unit
863 Figure 30 11 Tamper Unit, Staple Unit
Table 1 Plug / Jack Location List
Plug /
Jack
Number
Figure
Number
Item
Number Figure Title
