Xerox PHASER 7500 Service Manual

Phaser 7500 Printer Service Manual 2-43
Theory of Operation
Tray 1 Nudger Position Sensor (PL13.2.20)
Tray 1 Nudger Position Sensor detects the position of the Nudger Roll.
Note
Nudger Roll lowered: Sensor blocked
Tray 1 Feed Out Sensor (PL13.4.16)
Tray 1 Feed Out Sensor detects whether paper was fed from Tray 1 by changes in
the Actuator.
Note
No paper: Sensor blocked

Xerox PHASER 7500 Specifications

General

Max Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	150, 000 pages
Standard Paper Capacity	550 sheets
Duplex Printing	Optional
Standard Memory	256 MB
Network Connectivity	10/100/1000Base-T Ethernet
Supported Operating Systems	Windows, Mac OS, Linux
Max Paper Capacity	2, 100 sheets
Connectivity	USB 2.0, Ethernet
PDL	PostScript 3, PCL 6, PDF
Print Speed	Up to 35 ppm
