Phaser 7500 Printer Service Manual 2-65

Theory of Operation

STM T/A Motor Assembly (PL11.5.2)

TM Takeaway Motor (PL10.9.5)

s7500-419

Tray 3 Takeaway Motor

Assembly

Gear(34T)

Tray 3 Takeaway Roller Assembly

s7500-420

Gear(34T)

Gear(26T)

Gear(39T)

TM Take Away

Motor

Gear(39T)

Takeaway Roller 3

Takeaway Roller 2

Takeaway Roller 4
