10-12 Phaser 7500 Printer Service Manual
Plug/Jack and Wiring Diagrams
Duplex Unit Plug/Jack Designators
Duplex Unit Plug/Jack Designators
P/J Map Coordinates Remarks
175 13 F-308 Connection between the Duplex Wait Sensor
(PL14.6.8) and the Wire Harness (Dup)
(PL14.6.27)
176 13 H-307 Connection between the Duplex Cover Switch
(PL14.6.25) and the Wire Harness (Dup)
(PL14.6.27)
275 13 I-307 Connection between the Duplex Motor (PL14.5.8)
and the Wire Harness (Dup) (PL14.6.27)
4601 13 I-306 Connection between the Wire Harness (Dup)
(PL14.6.27) and the IOT
U303 3 C-105 Configuration Card connection

Xerox PHASER 7500 Specifications

General

Max Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	150, 000 pages
Standard Paper Capacity	550 sheets
Duplex Printing	Optional
Standard Memory	256 MB
Network Connectivity	10/100/1000Base-T Ethernet
Supported Operating Systems	Windows, Mac OS, Linux
Max Paper Capacity	2, 100 sheets
Connectivity	USB 2.0, Ethernet
PDL	PostScript 3, PCL 6, PDF
Print Speed	Up to 35 ppm
