Xerox PHASER 7500 Service Manual

3-210 Phaser 7500 Printer Service Manual
Error Messages and Codes
Tray Module Kind Mismatch
I/F mismatch between the IOT and the Tray Module was detected.
Applicable Chain-Link Code
• 077-211: Tray Module Kind Mis-match (Incorrect Tray Module from another
product)
Initial Actions
• Power cycle the printer.
• If the problem persists, follow the procedure below.
1. Check the DIP Switch setting on the 3TM or STM module.
• On the 3TM, all DIP switches should be On.
• On the STM, only switch 2 should be On.
2. Check the following connections for open circuits, short circuits, and poor
contacts.
• Between the Motor Drive PWB J509 and the TM Relay PWB J801
• When 3TM is connected: Between the TM Relay PWB J800 and the Tray
Module PWB J541
• When STM is connected: Between the TM Relay PWB J800 and the STM
PWB J541
3. If no problems are found, replace the following parts in sequence:
• When 3TM is connected: Tray Module PWB (REP 10.9, page 8-97)
• When STM is connected: STM PWB (REP 11.10, page 8-120)
• STM Relay PWB (REP 18.14, page 8-205)
• Motor Drive PWB (REP 18.13, page 8-204)
• MCU PWB (REP 18.12, page 8-202)
Troubleshooting Reference
Applicable Parts Wiring and Plug/Jack Map References
■ Tray Module PWB, PL10.9.1
■ STM PWB, PL11.5.4
■ MCU PWB, PL18.3.6
■ Motor Drive PWB, PL18.3.7
■ STM Relay PWB, PL18.3.11

Xerox PHASER 7500 Specifications

General

Max Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	150, 000 pages
Standard Paper Capacity	550 sheets
Duplex Printing	Optional
Standard Memory	256 MB
Network Connectivity	10/100/1000Base-T Ethernet
Supported Operating Systems	Windows, Mac OS, Linux
Max Paper Capacity	2, 100 sheets
Connectivity	USB 2.0, Ethernet
PDL	PostScript 3, PCL 6, PDF
Print Speed	Up to 35 ppm
