Xerox PHASER 7500 Service Manual

1-26 Phaser 7500 Printer Service Manual
General Information
Maintenance Function
Firmware Update
The Image Processor Board firmware can be updated by customers and service
technicians using Windows PC or Macintosh with dedicated utilities. Firmware
updates are available at www.xerox.com/office/P7500support.
Note
Refer to “Firmware Update” on page 11-14 for detailed procedure.
Diagnostics
Two types of diagnostic functions are available:
1. Power On Self Test: The controller board is checked at every Power On. The
CPU, ROM, and RAM are verified by the boot loader for integrity before the
POST firmware can be loaded to verify the Controller Board, but other system
components are not required for POST to run.
2. Service Diagnostics: Only qualified service personnel can perform manual
diagnostics using the Service Mode in the Control Panel (refer to “General
Troubleshooting” on page 4-1).
Updated Firmware Via Network (port 9100)
Image Processor Board Available
MCU Board Available

Xerox PHASER 7500 Specifications

General

Max Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	150, 000 pages
Standard Paper Capacity	550 sheets
Duplex Printing	Optional
Standard Memory	256 MB
Network Connectivity	10/100/1000Base-T Ethernet
Supported Operating Systems	Windows, Mac OS, Linux
Max Paper Capacity	2, 100 sheets
Connectivity	USB 2.0, Ethernet
PDL	PostScript 3, PCL 6, PDF
Print Speed	Up to 35 ppm
