Phaser 7500 Printer Service Manual 3-309
Error Messages and Codes
2nd BTR Unit Near End Warning/ 2nd BTR Unit End Warning
The 2nd BTR needs to be replaced soon.
The 2nd BTR must be replaced.
Applicable Chain-Link Codes
• 094-419: 2nd BTR Unit Near End Warning
• 094-422: 2nd BTR Unit End Warning
Initial Actions
• Power cycle the printer.
• If the problem persists, follow the procedure below.
1. Replace the 2nd BTR Assembly (REP 14.2, page 8-147).
Troubleshooting Reference
Applicable Parts Wiring and Plug/Jack Map References
■ 2nd BTR Assy, PL 14.2.1
