5-42 Phaser 7500 Printer Service Manual
Print-Quality Troubleshooting
IQ-15 Photoreceptor Pitch Color Stripes
Vibrations during the Imaging Unit CRU transportation may cause scrapes and
friction in the BCR and the Photoreceptor, resulting in leftover electrostatic
memory on the Photoreceptor that generates thin white streaks in the FS direction
on the highlight portion at the Photoreceptor Pitch.
Cause
This problem may occur right after the replacement of Imaging CRU (occurs at
Halftone image quality).
Initial Actions
• Check the paper transfer path.
• Ensure there are no debris on the transfer path.
Troubleshooting Reference
Applicable Parts Example Print
Photoreceptor Pitch Color Stripes
To Next Page
