3-190 Phaser 7500 Printer Service Manual
Error Messages and Codes
LPH Latch Timing Fail M/ LPH FFC Connect Fail M
LPH latch timing correction error.
The FFC connector is detected to have poor contact during LPH latch timing
control.
Note
Because this error is detected for each color at every cycle-up, perform at least
four jobs after turning the power Off and On.
Applicable Chain-Link Codes
• 061-391: LPH FFC Connect Posi Fail M
• 061-395: LPH FFC Connect Nega Fail M
Initial Actions
• Power cycle the printer.
• If the problem persists, follow the procedure below.
1. Turn the power Off and On.
2. Check the following:
• The Flat Cable between the MCU PWB J556 and the LPH Rear PWB (M)
J560 for open circuit, short circuit, and poor contact.
• The Flat Cable between the LPH H PWB (M) J568 and the LPH (M) J576
for open circuit, short circuit, and poor contact (connection within the LPH
Unit).
• The connector (P/J580) between the LPH Rear PWB (M) and the LPH H
PWB (M) for damage and debris.
• The LPH Unit (M) for improper installation.
3. If no problems are found, replace the following parts in sequence:
• LPH Unit (M) (REP 2.1, page 8-18)
• LPH Cable Assembly
• LPH Rear PWB (M) (REP 2.4, page 8-22)
• MCU PWB (REP 18.12, page 8-202)
Troubleshooting Reference
Applicable Parts Wiring and Plug/Jack Map References
■ LPH Unit (M), PL2.1.2
■ LPH Cable Assy, PL2.2.1
■ LPH Rear PWB (M), PL2.2.5
■ MCU PWB, PL18.3.6

Xerox PHASER 7500 Specifications

General

Max Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	150, 000 pages
Standard Paper Capacity	550 sheets
Duplex Printing	Optional
Standard Memory	256 MB
Network Connectivity	10/100/1000Base-T Ethernet
Supported Operating Systems	Windows, Mac OS, Linux
Max Paper Capacity	2, 100 sheets
Connectivity	USB 2.0, Ethernet
PDL	PostScript 3, PCL 6, PDF
Print Speed	Up to 35 ppm
