Xerox PHASER 7500 Service Manual

Phaser 7500 Printer Service Manual 4-5
General Troubleshooting
POST Soft Fault Messages
When POST detects a soft error, the printer continues the startup process. Before
the printer reaches Ready state, the Startup page is printed with soft errors
appearing in a red box. The box contains all soft faults encountered, with the
upper left corner of the box in the center of the Startup page, and extending to the
right margin, similar to the one shown here.
These messages are substituted for <device>:
•Ethernet
•Real-Time Clock
•Max RAM Limit
For ethernet, and real-time clock errors, replace the Image Processor Board. For
memory errors, see “RAM Errors” on page 4-17.
16 Min RAM
Limits
H: 16 Checks if sufficient
RAM installed.
17 Max RAM
Limits
S: 17 (POST_DEV_DIMM) Test performed.
20 IDE Disk S: 20
(POST_DEV_IDEOPT)
No test performed.
24 CPU Fan H: 24 No test performed.
Passive heatsink.
25 Cage Fan H: 25 No test performed.
14 Real Time
Clock
Tes t perfo rmed.
POST Test Descriptions (Continued)
Test No. Te st Name Fault Code (Hard, Soft) Description
Hardware Failure:
<device>:
General Failure

Xerox PHASER 7500 Specifications

General

Max Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	150, 000 pages
Standard Paper Capacity	550 sheets
Duplex Printing	Optional
Standard Memory	256 MB
Network Connectivity	10/100/1000Base-T Ethernet
Supported Operating Systems	Windows, Mac OS, Linux
Max Paper Capacity	2, 100 sheets
Connectivity	USB 2.0, Ethernet
PDL	PostScript 3, PCL 6, PDF
Print Speed	Up to 35 ppm
