Xerox PHASER 7500 Service Manual

1-12 Phaser 7500 Printer Service Manual
General Information
Specifications
Printer Specifications
Characteristic Specifications
Printing Technology Recording System: Electrophotographic method that
uses OPC Drum and Intermediate Transfer Belt
Charging System: Includes contact charge (BCR) and
roll type cleaner
Development System: Dry type two-component
magnet roller method that uses EA-HG toner, 5.8
microns in diameter (C, M, Y, K)
Exposure System: LED Print Head
Transfer System: Roller method using both primary
and secondary transfers
Fusing System: Heat and pressure fusing with free belt
nip method
Cleaning Method:
■ Imaging Unit: Cleaning Blade
■ IBT: Cleaning Blade
Printer Life 1,500,000 pages
Maximum Duty Cycle Up to 150,000 pages/month*
Recommended AMPV Up to 17,000 pages/month
Color Medium Cyan, Magenta, Yellow, and Black Print Cartridges
Print-Quality Mode
(dpi)
■ Standard: 1200 x 600x 1
■ Enhanced: 1200 x 1200 x 1
■ Photo: 600 x 600 x 4
Average Image
Coverage
Color 5% each CMY
Mono 5%
Average Job Size 5 pages
Maximum Image
Coverage
240% for all C, M, Y, K combined
First Page Output Time As fast as 7 seconds
Operating System Windows 2000/ 2003 Server/ XP/ Vista
Macintosh OS 10.3 or higher, Intel Mac
Linux
■ Solaris 8, 9, 10
■ HPUX 11.0 and 11iv2
■ AIX 5I v5.3
■ Linux Fedora Cora 1 and 5
■ Redhat Enterprise Linux 4
■ Suse Linux 10.0 and 11.x
* Assumes a 30 day month of printing.

Xerox PHASER 7500 Specifications

General

Max Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	150, 000 pages
Standard Paper Capacity	550 sheets
Duplex Printing	Optional
Standard Memory	256 MB
Network Connectivity	10/100/1000Base-T Ethernet
Supported Operating Systems	Windows, Mac OS, Linux
Max Paper Capacity	2, 100 sheets
Connectivity	USB 2.0, Ethernet
PDL	PostScript 3, PCL 6, PDF
Print Speed	Up to 35 ppm
