Phaser 7500 Printer Service Manual 2-59
Theory of Operation
Fuser Drive Motor Assembly (PL3.1.10)
Exit Motor (PL17.1.15)
s7500-411
Fuser Assembly
Exit Roller
[Fuser Assembly]
Heat Roller
[Fuser Assembly]
Helical Gear (26T)
Gear Bracket Assembly
Fuser Drive Motor
1st BTR Contact
Retract Clutch
Helical Gear
(45T/23T)
Helical Gear (36T)
Helical Gear (25T)
IBT Belt Unit
s7500-412
Gear(24T)
Gear Pulley (41T/16T)
Belt
Exit Roller
Exit Motor
