3-36 Phaser 7500 Printer Service Manual
Error Messages and Codes
Tray 2 Feed Out Sensor Static Jam
When the power was turned ON, the M/C was stopped (Cycle Down/ Shut Down),
or when the interlocks were closed (all interlocks including options), the Tray 2 Feed
Out Sensor detected paper.
Applicable Chain-Link Code
072-900: IOT Static Jam (at Tray 2 Feed Out Sensor)
Initial Actions
• Check the paper path for debris.
• If the problem persists, follow the procedure below.
1. Check the Tray 2 Feed Out Sensor for remaining paper, contamination,
Actuator return failure, or improper installation.
2. Perform the Tray Feed Sensors test in Diagnostics.
3. When 3TM is connected, check the connection between the Tray 2 Feed Out
Sensor J108-1 and the Tray Module PWB J549-A3 for short circuit.
4. When STM is connected, check the connection between the Tray 2 Feed Out
Sensor J108-1 and the STM PWB J548-3 for short circuit.
5. Check the connection between the Motor Drive PWB J509-6 and the TM Relay
PWB J801-10 for short circuit.
6. When 3TM is connected, check the connection between the TM Relay PWB
J800-A6 and the Tray Module PWB J541-6 for short circuit.
7. When STM is connected, check the connection between the TM Relay PWB
J800-A6 and the STM PWB J541-6 for short circuit.
8. If no problems are found, replace the following parts in sequence:
• Tray Module PWB (REP 10.9, page 8-97)
• TM Relay PWB (REP 18.14, page 8-205)
• Motor Drive PWB (REP 18.13, page 8-204)
• MCU PWB (REP 18.12, page 8-202)
Troubleshooting Reference
Applicable Parts Wiring and Plug/Jack Map References
â– Tray Module, PL10.9.1
â– TM Relay PWB, PL18.3.11
â– MCU PWB, PL18.3.6
â– Motor Drive PWB, PL18.3.7
To Next Page
