2-58 Phaser 7500 Printer Service Manual
Theory of Operation
Drum/ Deve Drive Motor (Y/M/C) (PL3.3.5)
IBT Drive Motor Assembly (PL3.3.4)
Drum (Y)
Developer
Housing Assembly (M)
Drum/Developer
Drive Motor (Y, M, C)
Drive Assembly
Drum (C)
Developer
Housing Assembly (C)
Drum (M)
Developer Housing
Assembly (Y)
Magnet Roll
Auger
s7500-388
s7500-389
IBT Drive Motor
Drive Assembly
IBT Belt Unit
