Xerox PHASER 7500 Service Manual

3-256 Phaser 7500 Printer Service Manual
Error Messages and Codes
Drum CRUM Y Communication Fail
Communication failure with Drum (Y) was detected.
Applicable Chain-Link Code
• 091-917: Drum CRUM Y Communication Fail
Initial Actions
• Power cycle the printer.
• If the problem persists, follow the procedure below.
1. Turn the power Off and On.
2. Check the following:
• The connection between the Motor Drive PWB J526 and the Drum CRUM
Coupler Assembly (Y) P112 for open circuit, short circuit, and poor contact.
• The connection terminals between the Drum (Y) CRUM PWB and the
Drum CRUM Coupler Assembly (Y) CRUM for damage and debris.
• The Drum (Y) CRUM PWB for contamination or disengagement.
• The Imaging Unit (Y) for improper installation.
3. If no problems are found, replace the following parts in sequence:
•Imaging Unit (Y) (REP 1.2, page 8-10)
• Drum CRUM Coupler Assembly (Y) (PL8.1.3)
• Motor Drive PWB (REP 18.13, page 8-204)
• MCU PWB (REP 18.12, page 8-202)
Troubleshooting Reference
Applicable Parts Wiring and Plug/Jack Map References
■ Drum CRUM Coupler Assy (Y),
PL8.1.3
■ Imaging Unit, PL8.1.4
■ MCU PWB, PL18.3.6
■ Motor Drive PWB, PL18.3.7

Xerox PHASER 7500 Specifications

General

Max Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	150, 000 pages
Standard Paper Capacity	550 sheets
Duplex Printing	Optional
Standard Memory	256 MB
Network Connectivity	10/100/1000Base-T Ethernet
Supported Operating Systems	Windows, Mac OS, Linux
Max Paper Capacity	2, 100 sheets
Connectivity	USB 2.0, Ethernet
PDL	PostScript 3, PCL 6, PDF
Print Speed	Up to 35 ppm
